Siemens 6ES7153-2BA70-0XB0 interface DP/PA-Link and ET200M IM153-2 HF In stock

Siemens 6ES7153-2BA70-0XB0 interface DP/PA-Link and ET200M IM153-2 HF In stock

Product Name: interface DP/PA-Link and ET200M IM153-2 HF

Brand Name:Siemens

Model Number:6ES7153-2BA70-0XB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

pa link and et200m im153 2 hf in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7153-2BA70-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	6ES7153-2BA70-0XB0
Product Type	IM 153-2 HF Interface Module
System Family	SIMATIC ET 200M
Communication Protocol	PROFIBUS DP (RS-485)
Transmission Rate	Up to 12 Mbit/s
Supply Voltage	24 VDC
Voltage Range	20.4 – 28.8 VDC
Current Consumption	Max. 650 mA
Backplane Bus Output	Max. 1.5 A
Power Dissipation	Approx. 5.5 W
Module Capacity	Up to 12 S7-300 modules
Input/Output Address Area	244 bytes / 244 bytes
Time Stamping Accuracy	1 ms (up to 8 modules)
Diagnostics	LED + system diagnostics
Protection Class	IP20
Isolation Voltage	500 V
Dimensions (W × H × D)	40 × 125 × 117 mm
Weight	Approx. 360 g

Description

The 6ES7153-2BA70-0XB0 is a Siemens SIMATIC DP interface module designed for ET 200M distributed I/O systems, supporting PROFIBUS DP communication with high reliability and extended functionality. It enables seamless integration of up to twelve S7-300 modules per station, making it suitable for complex automation architectures requiring scalable I/O expansion.

Engineered with High Feature (HF) capabilities, the 6ES7153-2BA70-0XB0 supports redundancy operation, time stamping, isochronous mode processing, and advanced diagnostic functions. It also provides enhanced support for HART variables and high-channel modules, ensuring precise data handling in demanding industrial environments.

As part of Siemens’ distributed automation portfolio, the 6ES7153-2BA70-0XB0 delivers robust performance for synchronized control systems, enabling efficient communication between field devices and PLC platforms in process automation, manufacturing, and infrastructure applications.

Applications

Power plants: Used for turbine monitoring, generator control systems, and protection relay integration.
Substations: Enables high-speed communication for switchgear control and differential protection systems.
Chemical plants: Supports process automation, HART-enabled instrumentation, and safety monitoring systems.
Steel mills: Ensures reliable operation in high-temperature and high-EMI industrial environments.
Machinery manufacturing plants: Used in production lines, robotics systems, and automated assembly control.
Oil & gas facilities: Supports distributed field instrumentation and remote process control.
Water treatment plants: Provides stable I/O communication for pumps, valves, and process monitoring.

Features

Supports up to 12 S7-300 modules
PROFIBUS DP High Feature interface
Redundancy-capable design
Integrated time stamping function
Isochronous mode support
Enhanced HART variable handling
Advanced diagnostic capabilities

Functions

Connects ET 200M stations to PROFIBUS DP networks
Enables synchronized distributed I/O communication
Supports high-precision event time stamping
Facilitates redundant system configurations
Enhances process data exchange reliability
Manages large-scale automation modules
Supports industrial real-time control applications

FAQ

Q1: What is the main function of the 6ES7153-2BA70-0XB0?
A1: It serves as a PROFIBUS DP interface module for ET 200M systems, enabling communication with up to 12 S7-300 modules.

Q2: Does the module support redundancy?
A2: Yes, it supports redundancy capability for high-availability automation systems.

Q3: What communication protocol does it use?
A3: It uses PROFIBUS DP over RS-485 with speeds up to 12 Mbit/s.

Q4: Can it perform time stamping?
A4: Yes, it supports high-accuracy time stamping for process events.

Q5: Which industries commonly use this module?
A5: It is widely used in power plants, chemical processing, manufacturing, and infrastructure automation systems.
