Siemens 6ES7153-2BB00-0XB0 SIMATIC ET 200M IM 153-2 FO High Feature Interface Module

Siemens 6ES7153-2BB00-0XB0 SIMATIC ET 200M IM 153-2 FO High Feature Interface Module

Product Name: SIMATIC ET 200M IM 153-2 FO High Feature Interface Module

Brand Name: Siemens

Model Number: 6ES7153-2BB00-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7153 2bb00 0xb0 simatic et 200m im 153 2 fo high feature interface module-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The Siemens 6ES7153-2BB00-0XB0 SIMATIC ET 200M IM 153-2 FO High Feature Interface Module is a high-performance fiber optic interface module designed for SIMATIC ET 200M distributed I/O systems. It features integrated fiber optic communication, PROFIBUS DP transmission rates up to 12 Mbit/s, support for up to eight S7-300 I/O modules, 128-byte input and output address spaces, and high-precision signal time stamping for advanced automation applications. Designed to enable reliable distributed communication and efficient data exchange, the module improves network stability, simplifies diagnostics, and enhances system availability. Its compatibility with SIMATIC ET 200M platforms makes it an ideal solution for process automation, manufacturing, power generation, and distributed industrial control applications.

Specifications

Product Name	Siemens 6ES7153-2BB00-0XB0 SIMATIC ET 200M IM 153-2 FO High Feature Interface Module
Manufacturer	Siemens
Product Type	SIMATIC ET 200M IM 153-2 FO High Feature Interface Module
Part Number	6ES7153-2BB00-0XB0
Place of shipment	Xiamen, China
Country of origin	Germany
Supply Voltage	24 VDC
Permissible Supply Voltage	20.4 to 28.8 VDC
Maximum Current Consumption	500 mA
Typical Inrush Current	3.5 A
Backplane Bus Output	5 VDC, max. 1 A
Typical Power Loss	4.5 W
Maximum S7-300 Modules	8
Input Address Space	128 Bytes
Output Address Space	128 Bytes
Time Stamp Accuracy	10 ms (3 ms resolution for time stamping)
Message Buffers	15
Messages per Buffer	20
Maximum Time-Stampable Digital Inputs	128
Time Format	RFC 1119 Internet (ISP)
Time Resolution	1 ms
Message Buffer Transmission Interval	1000 ms
Signal Time Stamping	Rising and falling edge
Communication Interface	Integrated Fiber Optic (FOC)
PROFIBUS DP Address Range	1 to 125
Maximum PROFIBUS Transmission Rate	12 Mbit/s
Supported Transmission Rates	9.6 kbit/s to 12 Mbit/s
Transmission Medium	Fiber Optic, 660 nm
Optical Connector	2 × Duplex Optical Sockets
Automatic Baud Rate Detection	Yes
SYNC Capability	Yes
FREEZE Capability	Yes
Direct Data Exchange	Yes (Slave-to-Slave, Sender)
Bus Protocol	PROFIBUS DP (EN 50170)
GSD Files	SIEM8071.GSD, SI018071.GSG, SI028071.GSG
Isolation Voltage	500 V
Degree of Protection	IP20
Operating Temperature	0 to 60 °C
Maximum Installation Altitude	3000 m

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

High-Speed Fiber Optic Communication
Utilizes integrated fiber optic technology to provide reliable PROFIBUS DP communication with excellent resistance to electromagnetic interference in demanding industrial environments.

Advanced Distributed I/O Integration
Supports seamless connection of ET 200M remote I/O stations, enabling efficient expansion and centralized management of distributed automation systems.

Precision Signal Time Stamping
Provides high-accuracy event time stamping for digital signals, improving process analysis, diagnostics, and event sequence recording in critical applications.

Flexible PROFIBUS DP Connectivity
Supports a wide range of PROFIBUS DP transmission speeds with automatic baud rate detection, ensuring simple integration into existing industrial communication networks.

Comprehensive Diagnostic Functions
Features message buffering, event recording, and advanced communication capabilities to simplify maintenance, improve troubleshooting efficiency, and reduce system downtime.

Ideal for Industrial Automation
Well suited for process automation, manufacturing plants, power generation, water treatment, and other industrial applications requiring reliable distributed I/O communication over fiber optic networks.

FAQ

Q1: What is the 6ES7153-2BB00-0XB0 used for?
A: The 6ES7153-2BB00-0XB0 is a fiber optic interface module used to connect SIMATIC ET 200M distributed I/O stations to PROFIBUS DP automation networks.

Q2: Which communication protocol does the 6ES7153-2BB00-0XB0 support?
A: The 6ES7153-2BB00-0XB0 supports the PROFIBUS DP communication protocol with integrated fiber optic transmission.

Q3: How many S7-300 modules can the 6ES7153-2BB00-0XB0 support?
A: The 6ES7153-2BB00-0XB0 supports up to eight S7-300 I/O modules within a SIMATIC ET 200M distributed I/O station.

Q4: Does the 6ES7153-2BB00-0XB0 support signal time stamping?
A: Yes. The 6ES7153-2BB00-0XB0 provides high-precision signal time stamping to improve event recording and process diagnostics.

Q5: What are the communication advantages of the 6ES7153-2BB00-0XB0?
A: The 6ES7153-2BB00-0XB0 combines high-speed fiber optic communication, automatic baud rate detection, and advanced PROFIBUS DP functions to ensure stable and efficient industrial networking.

Q6: Which industrial applications are suitable for the 6ES7153-2BB00-0XB0?
A: The 6ES7153-2BB00-0XB0 is widely used in process automation, factory automation, power generation, manufacturing, distributed I/O systems, and other industrial applications requiring reliable fiber optic PROFIBUS communication.
