Siemens 6ES7154-8AB01-0AB0 SIMATIC DP IM154-8 PN/DP Distributed CPU Module

Siemens 6ES7154-8AB01-0AB0 SIMATIC DP IM154-8 PN/DP Distributed CPU Module

Product Name: SIMATIC DP IM154-8 PN/DP Distributed CPU Module

Brand Name: Siemens

Model Number: 6ES7154-8AB01-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Commercial Terms
Overview
Features
Product Applications
Why Choose US
Other Products
Recommended Products

Contact Info

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7154-8AB01-0AB0 SIMATIC DP IM154-8 PN/DP Distributed CPU Module
Manufacturer	Siemens
Product Type	SIMATIC DP IM154-8 PN/DP Distributed CPU Module
Part Number	6ES7154-8AB01-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Protection Degree	IP65/IP67
Work Memory	384 KB integrated
Maximum MMC Capacity	8 MB
Data Retention on MMC	Minimum 10 years
Supply Voltage	24 V DC
Rated Load Voltage L+	24 V DC
Permissible Voltage Range	20.4…28.8 V DC
Typical Current Consumption	350 mA
Current Consumption (STOP/No-load)	250 mA
Inrush Current	2 A
I²t Value	0.25 A²·s
Typical Power Loss	8.5 W
Integrated Power Supply	Yes, 24 V DC
Number of DP Masters	1 integrated
Maximum Modules per Rack	16
Clock Backup Time	6 weeks at 40 °C
Clock Accuracy	Max. 10 s/day (Typical 2 s/day)
Communication Interfaces	MPI/PROFIBUS DP + PROFINET
PROFIBUS Interface	Integrated RS485
PROFIBUS Function	DP Master / DP Slave
PROFINET Interface	Integrated
PROFINET Ports	3 ports
Simultaneous Status Blocks	Up to 2
Number of Breakpoints	4
Maximum Status/Control Variables	30

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Overview

The Siemens 6ES7154-8AB01-0AB0 SIMATIC DP IM154-8 PN/DP Distributed CPU Module is a powerful distributed CPU module designed for decentralized automation systems based on Siemens SIMATIC technology. Combining CPU functionality with integrated PROFINET and PROFIBUS DP communication interfaces, it enables flexible control architectures and efficient integration of distributed I/O stations. With 384 KB integrated work memory, robust IP65/IP67 protection, and support for both DP Master and DP Slave operation, the module provides reliable performance for demanding industrial automation applications requiring high availability, communication flexibility, and decentralized control.

Features

SIMATIC DP IM154-8 PN/DP distributed CPU module for decentralized automation systems
Integrated 384 KB work memory for efficient program execution
Supports MMC load memory up to 8 MB with long-term data retention
Operates with 24 VDC power supply (20.4–28.8 VDC range)
Integrated power supply for simplified system installation
IP65/IP67 protection rating for harsh industrial environments
Integrated MPI/PROFIBUS DP and PROFINET communication interfaces
Supports PROFIBUS DP Master and DP Slave functionality
Integrated RS485 PROFIBUS interface
Three integrated PROFINET ports for flexible network configuration
Low typical power consumption with 8.5 W power loss
Fast and reliable distributed control capability
Supports up to 2 simultaneous status blocks and 4 breakpoints
Allows monitoring and control of up to 30 status/control variables
Reliable clock backup capability up to 6 weeks at 40°C
Suitable for industrial automation systems requiring decentralized processing and communication

Product Applications

The Siemens 6ES7154-8AB01-0AB0 distributed CPU module is widely used in decentralized automation systems where local processing and high-speed communication are required. Typical applications include production lines, manufacturing cells, machine automation, process control systems, material handling equipment, automotive manufacturing, and complex industrial installations using distributed I/O architectures.

With integrated PROFINET and PROFIBUS DP communication capabilities, the module is ideal for connecting distributed field devices, remote I/O stations, and automation networks. It provides a flexible solution for OEM machinery, factory automation, and industrial control applications that require reliable local control, efficient network integration, and robust operation in demanding environments.
