Product Name: SIMATIC S7-300 IM174 Interface Module
Brand Name: Siemens
Model Number: 6ES7174-0AA10-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7174-0AA10-0AA0 SIMATIC S7-300 IM174 Interface Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-300 IM174 Interface Module |
| Part Number | 6ES7174-0AA10-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Communication Protocol | Isochronous PROFIBUS DP |
| Rated Supply Voltage | 24 V DC |
| Supply Voltage Range | 20.4–28.8 V DC |
| Maximum Current Consumption | 500 mA |
| Backplane Bus Current | 100 mA @ 5 V DC |
| Typical Power Loss | 12 W |
| 5 V Encoder Supply | 1.2 A max., cable length up to 25 m |
| 24 V Encoder Supply | 1.4 A max., cable length up to 100 m |
| Digital Input Delay | Minimum 15 μs |
| Maximum DI Cable Length | 100 m (shielded) |
| Digital Output Voltage | 24 V DC |
| Digital Output Current | 5–300 mA per channel |
| Digital Output Protection | Short-circuit protected |
| Maximum Output Load | 1 A resistive, 30 W lamp load |
| Digital Output Delay | Max. 500 μs |
| Maximum Switching Frequency | 500 Hz (resistive), 0.5 Hz (inductive) |
| Relay Contact Rating | 1 A @ 30 V |
| Relay Mechanical Life | 50,000 operations |
| Maximum Relay Cable Length | 600 m (shielded) |
| Analog Output Range | -10 V to +10 V |
| Analog Output Resolution | 15-bit (including sign) |
| Analog Drive Output Current | -3 to +3 mA |
| Minimum Load Impedance | 3.3 kΩ |
| Controller Enable Outputs | 4 relay contacts |
| Relay Switching Capacity | 30 V, 1 A, 30 VA |
| Stepper Output Current | Up to 60 mA |
| Stepper Pulse Frequency | Up to 750 kHz |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7174-0AA10-0AA0 SIMATIC S7-300 IM174 Interface Module is a high-performance motion control interface module designed for Siemens SIMATIC S7-300 automation systems. Supporting Isochronous PROFIBUS DP communication, the module provides high-speed, synchronized data exchange for precision motion control applications. It integrates digital I/O, analog outputs, encoder power supplies, relay outputs, and stepper control functions, making it an ideal solution for demanding machine automation and positioning systems.
The Siemens 6ES7174-0AA10-0AA0 IM174 Interface Module is widely used in industrial motion control and machine automation systems requiring synchronized communication and high-speed control. Typical applications include CNC machinery, packaging equipment, printing machines, conveyor systems, robotics, material handling equipment, assembly lines, and precision positioning systems.
The module is ideal for controlling servo drives, stepper motors, encoders, and other motion devices while providing accurate analog and digital signal processing. It serves as a reliable interface solution for OEM machinery, factory automation, and industrial motion control applications requiring deterministic communication, precise positioning, and dependable real-time performance.
