Product Name:compact power terminal solution
Brand Name:Siemens
Model Number:6ES7193-4CE000-0AA0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7193-4CE000-0AA0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 6ES7193-4CE000-0AA0, SIMATIC DP TM-P15S22-01 terminal module for ET 200S, Siemens power terminal solution |
| System Compatibility | ET 200S distributed I/O system, supports modular power module integration |
| Terminal Type | Screw-type terminals, provides secure and durable electrical connection |
| Terminal Configuration | 2x2 terminal connections, optimized AUX1 line integration without extra wiring |
| Module Width | 15 mm, designed for compact power module installation |
| Mounting Type | DIN rail mounting, stable installation in industrial control cabinets |
| Dimensions | 15 mm (W) × 119.5 mm (H) × 43 mm (D), ultra-compact modular design |
| Weight | Approx. 55 g, lightweight structure for easy handling and assembly |
| Connection Type | Direct power module interface, ensures stable auxiliary line distribution |
| Operating Use | Designed for industrial automation power distribution systems |
The 6ES7193-4CE000-0AA0 is a compact power terminal solution designed for efficient power distribution within the ET 200S distributed I/O system. It is specifically engineered for 15 mm wide power modules, ensuring stable electrical connectivity in modular automation architectures.
This terminal module features screw-type terminals that provide secure and vibration-resistant wiring for industrial environments. With a 2x2 terminal configuration, it supports reliable AUX1 line connections without additional terminal leads, simplifying installation and reducing wiring complexity.
As a key component in SIMATIC DP systems, the 6ES7193-4CE000-0AA0 ensures compact integration on DIN rail systems. Its lightweight and space-saving design make it ideal for high-density control cabinets requiring stable and organized power distribution.
Q1: What is the main function of 6ES7193-4CE000-0AA0?
A1: It is used as a terminal module for ET 200S systems to distribute power and auxiliary signals securely.
Q2: What type of terminals does it use?
A2: It uses screw-type terminals for strong and vibration-resistant electrical connections.
Q3: Is it compatible with all ET 200S modules?
A3: It is designed specifically for 15 mm wide power modules within the ET 200S system.
Q4: What is the installation method?
A4: It is mounted on standard DIN rails for stable cabinet integration.
Q5: Why is AUX1 connection important?
A5: AUX1 allows simplified power line integration without additional terminal leads, reducing wiring complexity.
|
