Product Name:TERMINAL MODULE TM-C120C FOR ET 200S COMPACT
Brand Name:Siemens
Model Number:6ES7193-4DL00-0AA0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7193-4DL00-0AA0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 6ES7193-4DL00-0AA0 |
| Product Type | ET 200S Terminal Module TM-C120C |
| System Compatibility | SIMATIC DP / ET 200S |
| Connection Type | Spring-loaded terminals |
| Connector Layout | 4 × 21 connectors |
| Supported Modules | 32-point I/O modules (2-wire) |
| Wiring Method | Direct field wiring |
| Installation Type | DIN rail mounting |
| Dimensions (W×H×D) | 120 × 132 × 43 mm |
| Weight | Approx. 250 g |
| Operating Temperature | 0 to 60 °C |
| Protection Class | IP20 |
The 6ES7193-4DL00-0AA0 is a SIMATIC DP TM-C120C terminal module designed for ET 200S compact distributed I/O systems. It provides a reliable and space-efficient wiring solution using spring-loaded terminals, ensuring fast installation and secure electrical connections in industrial automation environments.
As part of the Siemens ET 200S series, the 6ES7193-4DL00-0AA0 supports 4 × 21 connectors and is optimized for use with 32-point I/O modules in 2-wire configurations. Its robust mechanical design ensures stable signal transmission and long-term operational durability.
With compact dimensions and high-density connection capability, this terminal module improves system organization, reduces wiring complexity, and enhances overall control cabinet efficiency in modern automation applications.
Q1: What is the main use of 6ES7193-4DL00-0AA0?
A1: It is used as a terminal module for ET 200S systems to simplify field wiring and signal connection.
Q2: What type of terminals does it use?
A2: It uses spring-loaded terminals for fast and reliable wiring connections.
Q3: How many connectors does it support?
A3: It provides 4 × 21 connector layout for high-density wiring.
Q4: Which modules are compatible with it?
A4: It is designed for 32-point I/O modules in 2-wire configurations.
Q5: Where is it commonly applied?
A5: It is widely used in power plants, substations, chemical plants, and industrial automation systems.
|
