Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330103-05-10-10-12-05
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Probe |
| Brand Name | Bently Nevada |
| Model Number | 330103-05-10-10-12-05 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The Bently Nevada 330103-05-10-10-12-05 3300 XL 8 mm Probe is a high-precision proximity probe designed for vibration and position measurement in rotating industrial machinery. As part of the 3300 XL 8 mm probe family, it incorporates FluidLoc cable technology and a Miniature coaxial ClickLoc connector to provide enhanced protection in harsh operating environments. With a stainless steel body and a PPS probe tip, it delivers long-term stability and reliability for critical machinery monitoring applications.
Measures shaft vibration and radial displacement in rotating machinery
Converts mechanical motion into electrical signals using eddy current technology
Provides continuous real-time data for machinery protection systems
Supports condition monitoring and predictive maintenance strategies
Ensures accurate non-contact position sensing in extreme industrial environments
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330103-05-10-10-12-05 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330103-05-10-10-12-05 |
| Dimensions | 110x1.6x1.6cm |
| Weight | 0.08 kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 50 mm |
| Overall Case Length Option | 100 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, FluidLoc cable |
| Agency Approval Option | CSA, ATEX, IECEx Approvals |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating and Storage Temperature | -52°C to +177°C (-62°F to + 350°F) |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket |
FluidLoc cable technology for strong protection against liquids and contaminants
Miniature coaxial ClickLoc connector for secure and stable electrical connection
Total probe length: 1.0 meter (3.3 feet)
Housing length: 100 mm with 50 mm unthreaded section
PPS (Polyphenylene sulfide) probe tip for excellent thermal and chemical resistance
AISI 303/304 stainless steel housing for corrosion resistance and durability
Optional flexible stainless steel armor with FEP outer jacket for added mechanical protection
Wide operating temperature range: -52°C to +177°C
CSA, ATEX, and IECEx certified for global industrial safety compliance
Lightweight and compact design (0.08 kg)
High-accuracy eddy current sensing ensures precise vibration and displacement measurement
FluidLoc cable minimizes signal interference from moisture and harsh environments
Stable and reliable operation under extreme temperature conditions
Designed for continuous use in industrial rotating machinery systems
Optional armored configuration enhances mechanical strength and durability
Long service life with minimal maintenance requirements
Fully compliant with international industrial safety standards
Q1: What is the primary use of the Bently Nevada 330103-05-10-10-12-05?
A1: The Bently Nevada 330103-05-10-10-12-05 is used for vibration and position monitoring in rotating machinery such as turbines, compressors, and motors.
Q2: What technology does the 330103-05-10-10-12-05 use for measurement?
A2: The 330103-05-10-10-12-05 uses eddy current technology for accurate non-contact measurement of vibration and displacement.
Q3: Is the 330103-05-10-10-12-05 suitable for harsh industrial environments?
A3: Yes, the 330103-05-10-10-12-05 is designed for harsh environments with an operating range of -52°C to +177°C and FluidLoc protection.
Q4: What ensures the durability of the Bently Nevada 330103-05-10-10-12-05?
A4: The 330103-05-10-10-12-05 features stainless steel construction, PPS probe tip material, and optional armored cable for enhanced durability.
Q5: What certifications does the 330103-05-10-10-12-05 have?
A5: The 330103-05-10-10-12-05 is certified with CSA, ATEX, and IECEx approvals for safe use in global industrial environments.
Q6: In which industries is the 330103-05-10-10-12-05 commonly used?
A6: The 330103-05-10-10-12-05 is widely used in power generation, oil and gas, petrochemical plants, and heavy industrial machinery monitoring systems.
