Siemens SIMATIC S7-1200F 6ES7212-1AF40-0XB0 CPU 1212 FC Compact CPU DC/DC/DC

Siemens SIMATIC S7-1200F 6ES7212-1AF40-0XB0 CPU 1212 FC Compact CPU DC/DC/DC

SIEMENS · SIMATIC S7-1200F 6ES7212-1AF40-0XB0 CPU 1212 FC Compact CPU DC/DC/DC	Fail-safe CPU CPU 1212 FC DC/DC/DC
Digital I/O: 8 DI / 6 DO · Analog input: 2 AI · Memory: 150 KB
Order check: Confirm the complete article number, firmware, safety engineering and application before quotation. Email Inquiry WhatsApp [email protected] \| +86 18159889985

Overview
Applications
Data
Construction
Environment
Selection
Verification
Commercial
Models
Recommended Products

Official product overview

6ES7212-1AF40-0XB0 CPU 1212 FC compact fail-safe CPU

The Siemens 6ES7212-1AF40-0XB0 is a SIMATIC S7-1200F CPU 1212 FC compact fail-safe CPU. Siemens specifies a DC/DC/DC design with eight 24 V DC digital inputs, six 24 V DC digital outputs, two 0 to 10 V DC analog inputs, a 20.4 to 28.8 V DC supply range and 150 KB program/data memory.

Lifecycle note: Commercial availability, condition and delivery status are subject to verification.

Applications

System role

Compact fail-safe control with onboard I/O

Fail-safe and standard automation tasks engineered within a verified SIMATIC S7-1200F system.
Compact local control using eight integrated 24 V DC digital inputs and six 24 V DC digital outputs.
Integrated acquisition of two 0 to 10 V DC analog signals.
Projects engineered with the required STEP 7 safety options and validated application documentation.

Selection note: Safety suitability and system coordination must be confirmed before quotation.

Data

Siemens data sheet

Key technical values

Use the exact article number and the official Siemens data sheet when validating a project.

Product type	CPU 1212FC DC/DC/DC
Firmware version	V4.7
Engineering software	STEP 7 V20 or higher
Supply	20.4 to 28.8 V DC
Digital I/O	8 DI 24 V DC; 6 DO 24 V DC
Analog inputs	2 AI, 0 to 10 V DC
Program/data memory	150 KB
System expansion	Up to 3 communication modules, 1 signal board and 2 signal modules

Construction

Integrated fail-safe CPU and onboard I/O

The compact CPU integrates processing, DC supply, digital I/O and analog inputs in one S7-1200F device. Integrated outputs are DC outputs; confirm load characteristics and wiring in the current Siemens manual.

Interface check: Confirm terminal allocation, output loads, analog ranges, safety parameters and expansion hardware.

Environment

Protection and environment

Installation conditions

Apply the limits and approvals stated for the exact Siemens article.

Operating temperature	Confirm the permitted range and mounting-position limits in the current Siemens data sheet
Storage and transport	Subject to verification
Humidity and altitude	Confirm before quotation
Protection and approvals	Request current Siemens certificates required for the destination

Engineering note: Use the current Siemens safety and S7-1200 system manuals for installation restrictions.

Selection

System role

Installation and selection sequence

Match the complete 6ES7212-1AF40-0XB0 article number and exact CPU variant.
Confirm the power supply, output loads and onboard analog signal ranges.
Verify TIA Portal / STEP 7 version, CPU firmware and safety engineering requirements.
Check expansion modules, signal boards, communication modules, mounting and certificate requirements.

Selection note: Do not infer compatibility from a similar family designation.

Verification

Before order

Verification checklist

Complete article number and suffix	CPU firmware and STEP 7 version
Safety engineering requirements	DC supply and output loads
Analog-input range	Expansion and mounting compatibility
Current unit and nameplate photographs	Condition, testing, warranty, stock and dispatch terms

Match firmware, safety project, DC loads and expansion hardware before approval.

Commercial

Written confirmation

Commercial information before payment

Every commercial commitment is confirmed against the exact article and quoted unit.

Stock status	Confirm before quotation for the exact article number and requested quantity.
Condition	New, used or refurbished status is stated in the written quotation.
Photos / nameplate	Current unit and nameplate photos are available on request.
Test statement	Available on request and subject to the agreed test scope.
Warranty	Confirmed in the formal quotation.
Dispatch	Confirmed after stock, destination and order approval are verified.
Payment	Supported methods are listed in the formal quotation.
Quote response	Subject to verification and request completeness.
Transaction trust	Seller details, quotation, invoice and payment instructions are available for review before payment.
Product status	Actual stock, condition, testing, warranty and dispatch are subject to verification.
