Siemens 6ES7214-1AG40-0XB0 Compact CPU 1214C

Siemens 6ES7214-1AG40-0XB0 Compact CPU 1214C

Product Name: Compact CPU 1214C

Brand Name: Siemens

Model Number: 6ES7214-1AG40-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7214 1ag40 0xb0 compact cpu 1214c-1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7214-1AG40-0XB0 is a compact and high-performance programmable logic controller (PLC) designed for advanced industrial automation and motion control applications. As part of the Siemens SIMATIC S7-1200 family, this CPU 1214C features a DC/DC/DC configuration with DC power supply, DC digital inputs, and DC transistor outputs, providing fast response times and precise control capabilities.

Equipped with integrated high-speed counters, pulse outputs, analog inputs, and PROFINET communication, the controller supports complex automation, positioning, and process control tasks. Its scalable architecture, integrated diagnostics, and cybersecurity functions make it suitable for modern industrial systems requiring reliability, flexibility, and secure connectivity.

Functions

Executes automation logic and machine control operations.
Provides 14 digital inputs for monitoring industrial sensors and control signals.
Provides 10 high-speed transistor outputs for fast and precise device control.
Includes 2 analog inputs for voltage signal acquisition and process monitoring.
Supports high-speed motion and positioning control for up to 8 axes.
Performs pulse train output (PTO/PWM) control for servo and stepper motor applications.
Supports PID closed-loop control for temperature, pressure, and flow regulation.
Enables industrial Ethernet communication through integrated PROFINET interfaces.
Supports remote diagnostics, HMI communication, and OPC UA data exchange.
Expands automation capability through Siemens signal modules and communication modules.

Features

The Siemens 6ES7214-1AG40-0XB0 is designed as a high-performance compact controller with strong emphasis on motion control capability, system integration, and scalability for modern industrial automation.

High-speed motion control architecture with 6 × 100 kHz high-speed counters and 4 × 100 kHz PTO/PWM pulse outputs, supporting up to 8 positioning axes for precise servo and stepper applications.
Integrated high-speed processing performance with a typical bit operation speed of 0.08 µs, enabling fast response in time-critical automation tasks.
Flexible onboard I/O configuration including 14 digital inputs (24 V DC), 10 high-speed transistor outputs, and 2 analog inputs (0–10 V DC) for mixed-signal control applications.
Powerful integrated control functions such as PID regulation for closed-loop process control (temperature, pressure, flow, etc.).
Advanced communication capabilities via integrated PROFINET interface supporting IO Controller/Device roles, HMI connectivity, and industrial Ethernet communication (TCP/IP, UDP, ISO-on-TCP).
Scalable system architecture supporting up to 8 signal modules, 3 communication modules, and expansion boards, enabling growth from compact control to large distributed systems.
Industrial communication and data integration features including OPC UA server support (license-based) and built-in web server for remote diagnostics and system access.
Robust cybersecurity and access protection functions including multi-level password protection, user management, and program block copy protection.
Maintenance-free memory system with 150 KB work memory and 4 MB load memory, eliminating battery dependency and improving long-term reliability.
Wide DC operating range (20.4–28.8 V DC) with reverse polarity protection and stable power handling for harsh industrial environments.
