Product Name: CPU 1214C DC/DC/Relay
Brand Name: Siemens
Model Number: 6ES7214-1HG40-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Overview
The Siemens SIMATIC S7-1200 CPU 1214C DC/DC/Relay (Part Number: 6ES7214-1HG40-0XB0) is a compact programmable logic controller (PLC) designed for industrial automation and machine control applications. As a member of the Siemens SIMATIC S7-1200 series, it combines high-performance processing capability, integrated control functions, and flexible expandability in a compact design, making it suitable for small and medium-sized automation systems.
Operating with a 24 V DC power supply, the CPU 1214C DC/DC/Relay provides reliable relay outputs for controlling industrial devices such as motors, relays, valves, and indicators. It supports expansion through Siemens signal modules and communication modules, enabling efficient integration into various automation environments. Manufactured by Siemens in Germany, this PLC is widely used in manufacturing, packaging, conveyor systems, process control, and intelligent industrial automation applications.
Operates with 24 V DC rated power supply
Permissible input voltage range from 20.4 V to 28.8 V DC
Integrated relay outputs suitable for industrial load control
Stable processing performance for automation and machine control applications
CPU current consumption of 500 mA under rated operating conditions
Supports up to 1 500 mA current consumption with expansion modules connected
Maximum inrush current of 12 A at 28.8 V DC
Backplane bus capacity up to 1 600 mA at 5 V DC for SM and CM modules
Typical power loss of 12 W for efficient energy operation
Supports Siemens signal modules (SM) and communication modules (CM) for flexible system expansion
Compact and space-saving structure for easy control cabinet installation
High reliability and industrial-grade durability for continuous operation
Easy integration into Siemens TIA Portal automation platforms
Manufactured in Germany according to Siemens industrial quality standards
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7214-1HG40-0XB0 CPU 1214C DC/DC/Relay |
| Manufacturer | Siemens |
| Product Type | CPU 1214C DC/DC/Relay |
| Part Number | 6ES7214-1HG40-0XB0 |
| Estimated shipping dimensions | 11x9.3x7.5cm |
| Weight | 0.34kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Current consumption (rated value) | 500 mA; CPU only |
| Current consumption, max. | 1 500 mA; CPU with all expansion modules |
| Inrush current, max. | 12 A; at 28.8 V |
| I²t | 0.8 A²·s |
| for backplane bus (5 V DC), max. | 1 600 mA; Max. 5 V DC for SM and CM |
| Power loss, typ. | 12 W |
The Siemens 6ES7214-1HG40-0XB0 CPU 1214C DC/DC/Relay is widely used in industrial automation applications, including:
