16
Digital outputs |
24 V DC
Transistor outputs |
0.75 A
Per output |
Siemens SIMATIC S7-200 SMART 6ES7288-2QT16-0AA0 is the EM DT16 digital output module specified by Siemens with 16 transistor outputs for 24 V DC loads and a rated output current of 0.75 A per output.
Product type designation: SM DT16, DQ 16x24 V DC/0.75 A. The complete article number and application conditions must be confirmed before quotation.
Article number |
6ES7288-2QT16-0AA0 |
Series |
SIMATIC S7-200 SMART |
Official description |
Digital output EM DT16, 16 digital outputs, 24 V DC, transistor 0.75 A |
Core verified point |
16 transistor digital outputs at 24 V DC, 0.75 A per output |
|
Article number
|
6ES7288-2QT16-0AA0
|
|
Product type designation
|
SM DT16, DQ 16x24 V DC/0.75 A
|
|
Digital inputs
|
0
|
|
Digital outputs
|
16
|
|
Output technology
|
Transistor
|
|
Output voltage
|
24 V DC
|
|
Rated current per output
|
0.75 A
|
|
Rated supply voltage
|
24 V DC
|
|
Permissible supply range
|
20.4 V DC to 28.8 V DC
|
|
Backplane-bus current at 5 V DC, typical
|
135 mA
|
|
Output groups
DQ a.0 to DQ a.7 DQ b.0 to DQ b.7 |
Terminal blocks
X10, X11, X12 and X13 1L/1M through 4L/4M supply/common terminals |
The Siemens system manual identifies four terminal blocks and includes a functional-earth terminal in the assignment. Wiring must follow the exact pin table for 6ES7288-2QT16-0AA0.
Do not infer terminal positions from a similar module. Confirm conductor preparation, connector handling and the complete pin allocation in the current official manual before installation.
|
Compliance listing
|
The Siemens declaration lists 6ES7288-2QT16-0AA0 under EMC and RoHS, and under UK-EMC and UK-RoHS legal acts.
|
|
Environmental limits
|
Confirm the ambient temperature, humidity, altitude and pollution conditions in the current official documentation before installation.
|
|
Enclosure and IP selection
|
Subject to verification for the planned control-cabinet and installation environment.
|
|
Load-circuit protection
|
External protection and coordination must be confirmed from the official system manual for the actual load circuit.
|
|
Document revision
|
Confirm the currently applicable Siemens datasheet, system manual and declaration before quotation.
|
|
01
|
Confirm the complete part number: 6ES7288-2QT16-0AA0.
|
|
02
|
Confirm compatibility with the selected SIMATIC S7-200 SMART CPU and system configuration.
|
|
03
|
Confirm 24 V DC load voltage, current and switching characteristics.
|
|
04
|
Confirm grouped supply wiring, common terminals and permissible circuit loading.
|
|
05
|
Confirm terminal-block, conductor and protection requirements from the official manual.
|
|
06
|
Confirm certification, environment and documentation revision required by the destination project.
|
|
Identity
|
Match the full order number and suffix on the product nameplate.
|
|
Condition
|
Confirm New, Used or Refurbished before quotation.
|
|
Photos
|
Current physical-product and nameplate photos are available on request.
|
|
System fit
|
Verify the intended CPU, module position and system configuration.
|
|
Electrical fit
|
Verify load voltage, current, group supply and switching duty.
|
|
Wiring
|
Verify X10-X13 terminal assignment and conductor requirements.
|
|
Documents
|
Confirm the latest official datasheet, manual and declaration.
|
|
Commercial record
|
Check the written quotation, payee information and agreed transaction terms.
|
|
Real stock
|
Subject to verification. Request current inventory evidence before quotation.
|
|
Condition
|
New, Used or Refurbished: confirm before quotation.
|
|
Current photos
|
Physical-product and nameplate photos are available on request.
|
|
Warranty
|
Confirm before quotation.
|
|
Dispatch time
|
Confirm before quotation.
|
|
Testing
|
Subject to verification; available test records can be requested.
|
|
Payment methods
|
Available on request and subject to the written quotation.
|
|
Quotation response time
|
Subject to verification.
|
|
Transaction confidence
|
Request company details, a written quotation, payee verification and an agreed transaction record before payment.
|
|
