Product Name: CPU 314 Central Processing Unit
Brand Name: Siemens
Model Number: 6ES7314-1AE04-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7314-1AE04-0AB0 CPU 314 Central Processing Unit |
| Manufacturer | Siemens |
| Product Type | CPU 314 Central Processing Unit |
| Part Number | 6ES7314-1AE04-0AB0 |
| Weight | 0.48kg |
| Estimated shipping dimensions | 8x12.5x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Current consumption (rated value) | 1 000 mA |
| Inrush current, typ. | 8 A |
| Power loss, max. | 8 W |
| integrated | 24 kbyte; 24 KB/8 K instructions RAM (integrated); 1 instruction means 3 bytes on average |
| DB Number, max. | 127 |
| DB Size, max. | 8 kbyte |
The Siemens 6ES7314-1AE04-0AB0 is a SIMATIC S7-300 CPU 314 Central Processing Unit designed for reliable machine and process automation applications. As the core controller of an S7-300 system, it executes user programs, manages data processing, and coordinates communication between distributed I/O devices and automation components. Its robust industrial design and proven Siemens architecture make it suitable for a wide range of manufacturing, packaging, material handling, and process control applications.
The Siemens 6ES7314-1AE04-0AB0 combines efficient processing performance with compact installation requirements, making it an excellent choice for medium-sized automation tasks. Featuring integrated memory, flexible programming capabilities, and dependable operation under industrial conditions, it provides stable control performance while simplifying system integration and maintenance.
The primary function of the Siemens 6ES7314-1AE04-0AB0 is to serve as the central processing unit of an S7-300 automation system, executing control logic and managing system operations.
Key functions include:
Compared with conventional mid-range PLC processors, the Siemens 6ES7314-1AE04-0AB0 offers proven reliability, efficient program execution, and excellent compatibility within the SIMATIC automation ecosystem.
1. Reliable Industrial Performance
The Siemens 6ES7314-1AE04-0AB0 is built to Siemens industrial standards, providing stable operation and long service life in demanding automation environments.
2. Seamless S7-300 System Integration
Unlike generic PLC controllers, the Siemens 6ES7314-1AE04-0AB0 integrates directly with S7-300 modules, reducing engineering complexity and commissioning time.
3. Efficient Memory Management
Support for up to 127 data blocks and 8 KB DB size allows flexible program organization and structured data handling compared with entry-level PLC CPUs.
4. Compact and Space-Saving Design
The Siemens 6ES7314-1AE04-0AB0 provides powerful control capabilities while occupying minimal cabinet space.
5. Stable Power Operation
Its wide operating voltage range helps maintain reliable performance during voltage fluctuations that may affect less robust controllers.
6. Proven Siemens Engineering Platform
The Siemens 6ES7314-1AE04-0AB0 benefits from extensive Siemens software support, diagnostics, and lifecycle reliability, offering advantages over many third-party PLC solutions.
Q1: What is the main purpose of Siemens 6ES7314-1AE04-0AB0?
A: The Siemens 6ES7314-1AE04-0AB0 serves as the central processing unit of an S7-300 PLC system, executing automation programs and controlling industrial processes.
Q2: How much integrated memory does 6ES7314-1AE04-0AB0 provide?
A: The Siemens 6ES7314-1AE04-0AB0 includes 24 KB of integrated working memory for program execution and data processing.
Q3: How many data blocks can 6ES7314-1AE04-0AB0 support?
A: The Siemens 6ES7314-1AE04-0AB0 supports up to 127 data blocks, with a maximum size of 8 KB per data block.
Q4: What operating voltage is required for 6ES7314-1AE04-0AB0?
A: The Siemens 6ES7314-1AE04-0AB0 operates on 24 V DC and supports an input voltage range of 20.4 V DC to 28.8 V DC.
Q5: What applications are suitable for 6ES7314-1AE04-0AB0?
A: The Siemens 6ES7314-1AE04-0AB0 is commonly used in machine automation, production lines, packaging equipment, material handling systems, and process control applications.
