Siemens 6ES7314-1AG14-0AB0 SIMATIC S7-300 CPU module In stock

Siemens 6ES7314-1AG14-0AB0 SIMATIC S7-300 CPU module In stock

Product Name:SIMATIC S7-300 CPU module

Brand Name:Siemens

Model Number:6ES7314-1AG14-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7314 1ag14 0ab0 simatic s7 300 cpu module in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7314-1AG14-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7314-1AG14-0AB0, SIMATIC S7-300 CPU 314 central processing unit with MPI interface
CPU Type	Compact PLC CPU with integrated 24 V DC power supply for industrial automation
Work Memory	128 KB integrated working memory for program execution and data handling
Memory Card	Micro Memory Card required for load memory and system backup
Communication Interface	MPI RS485 interface supporting PG/OP and S7 communication
Supply Voltage	24 V DC rated input, operating range 19.2–28.8 V stable industrial power
Power Loss	Approx. 4 W low energy consumption CPU design
Dimension	40 × 125 × 130 mm compact modular S7-300 controller form factor
Weight	Approx. 280 g lightweight industrial CPU module
Mounting	DIN rail installation for standard S7-300 rack systems

Description

The 6ES7314-1AG14-0AB0 is a SIMATIC S7-300 CPU module developed by Siemens for compact yet powerful industrial automation control. It integrates a central processing unit with MPI communication and a built-in 24 V DC power supply, making it suitable for small to medium-scale PLC applications requiring stable performance.

The 6ES7314-1AG14-0AB0 offers 128 KB work memory and requires a Micro Memory Card for program storage and system backup. With firmware V3.3 and STEP 7 V5.5 compatibility, it ensures efficient programming, fast execution, and flexible system configuration within S7-300 environments.

Designed for reliable industrial operation, this CPU supports real-time control, distributed communication, and scalable automation architecture. It is widely used in machinery control, process automation, and infrastructure systems where stable logic processing and robust communication are required.

Applications

Power plants: Used for generator monitoring, auxiliary system control, and relay protection logic execution.
Substations: Enables switchgear control, signal acquisition, and electrical protection system coordination.
Chemical plants: Supports process automation, safety interlocking, and distributed control integration.
Steel mills: Ensures stable logic control under high temperature and strong electromagnetic interference conditions.
Machinery manufacturing: Applied in automated production lines, robotics, and packaging equipment control systems.

Features

Integrated MPI communication interface for reliable industrial networking
128 KB work memory for efficient program execution
Compact CPU design with built-in 24 V DC power supply
Requires Micro Memory Card for flexible data storage and backup
Compatible with STEP 7 programming environment for easy configuration

Functions

Executes real-time PLC logic control for industrial processes
Manages communication between field devices and control systems
Provides stable program execution with deterministic performance
Supports diagnostics and system monitoring functions
Enables scalable automation system integration in S7-300 architecture

FAQ

Q1: What is the main function of 6ES7314-1AG14-0AB0?
A1: It is a SIMATIC S7-300 CPU used for processing automation logic and controlling industrial systems.

Q2: Does this CPU require a memory card?
A2: Yes, it requires a Micro Memory Card for program storage and backup.

Q3: What communication interface does it support?
A3: It supports MPI communication via RS485 interface.

Q4: What programming software is compatible?
A4: It is compatible with STEP 7 V5.5 or higher versions.

Q5: Where is this CPU commonly used?
A5: It is widely used in machinery, chemical plants, power systems, and industrial automation control.
