Siemens 6ES7322-1BF01-0AA0 DIGITAL OUTPUT SM 322 Original new

Siemens 6ES7322-1BF01-0AA0 DIGITAL OUTPUT SM 322 Original new

Product Name:DIGITAL OUTPUT SM 322

Brand Name:Siemens

Model Number:6ES7322-1BF01-0AA0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7322 1bf01 0aa0 digital output sm 322 original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7322-1BF01-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7322-1BF01-0AA0
Manufacturer	Siemens
Product Series	SIMATIC S7-300
Product Type	Digital Output Module (SM 322)
Output Channels	8 DO
Output Voltage	24 V DC
Rated Output Current	2 A per channel
Load Voltage Range	20.4 – 28.8 V DC
Switching Type	Optically Isolated (Optocoupler)
Backplane Current	Max. 40 mA
Power Loss	Approx. 6.8 W
Switching Frequency	Up to 100 Hz (resistive load)
Cable Length Support	Up to 1000 m (shielded)
Dimensions	40 × 125 × 120 mm
Weight	approx. 0.19 kg
Mounting Type	Rack / S7-300 Backplane
Isolation Voltage	500 V DC

Description

The Siemens 6ES7322-1BF01-0AA0 is an optically isolated digital output module from the SIMATIC S7-300 series, designed for reliable switching control in industrial automation systems. It delivers stable 24 V DC output signals for driving actuators, relays, and field devices in medium-scale control applications.

The 6ES7322-1BF01-0AA0 provides 8 digital output channels with a rated current of up to 2 A per channel. It features optocoupler isolation between channels and backplane bus, ensuring high electrical safety and reducing interference in harsh industrial environments. Its compact 40 mm module width allows easy integration into S7-300 rack systems.

As part of the Siemens S7-300 automation platform, the 6ES7322-1BF01-0AA0 is widely used in manufacturing, energy systems, and process industries where reliable switching performance and stable output control are required.

Applications

Power Plants: Used for relay switching, turbine auxiliary control, and generator system output control.
Substations: Supports switchgear operation, protection signal output, and automation control systems.
Chemical Plants: Enables safe control of valves, pumps, and process actuators.
Steel Mills: Provides reliable switching in high temperature and high electromagnetic interference environments.
Machinery Manufacturing Plants: Used in automated production lines, robotic systems, and conveyor control.
Oil & Gas Facilities: Supports process shutdown systems, valve actuation, and safety control logic.
Water Treatment Plants: Controls pumps, dosing systems, and distributed automation devices.

Features

8-channel 24 V DC digital output module
Optically isolated channel design
High load capacity up to 2 A per channel
Compact 40 mm S7-300 module width
Stable industrial switching performance
Electrical noise resistant architecture
Easy integration into S7-300 rack system
Suitable for continuous industrial operation

Functions

Provides digital switching output signals
Controls industrial actuators and relays
Executes automation control commands
Ensures safe electrical isolation
Supports distributed control systems
Maintains stable output signal transmission
Enhances system reliability and uptime

FAQ

Q1: What is the main function of Siemens 6ES7322-1BF01-0AA0?
A1: It is a digital output module used to switch and control field devices in S7-300 systems.

Q2: How many output channels does it provide?
A2: It provides 8 digital output channels.

Q3: What is the rated output current per channel?
A3: Each channel supports up to 2 A at 24 V DC.

Q4: Is the module electrically isolated?
A4: Yes, it uses optical isolation between channels and backplane bus.

Q5: Where is this module commonly used?
A5: It is used in manufacturing, power plants, chemical processing, and automation systems.
