Product Name: Output (DO) module
Brand Name: Triconex
Model Number: 3625
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Triconex |
Model Number: |
3625 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Description |
Value |
|
Model |
3625 |
|
Type |
TMR Digital Output Module |
|
Output Points |
32 points |
|
System Compatibility |
Tricon v10.2 and later |
|
Architecture |
Triple Modular Redundant (TMR) |
|
Field Power Configuration |
16-point grouped power distribution |
|
Power Input |
Supports up to 4 independent field power sources |
|
Voltage Tolerance |
±5% between sources required |
|
Termination |
16-point commoned field termination panels |
|
Application Mode |
Energize-to-trip / De-energize-to-trip |
|
Dimensions |
305 mm × 152 mm × 89 mm |
|
Weight |
1.2 kg |
Triconex 3625A is a 32-point TMR digital output module for safety systems, designed for energize-to-trip and de-energize-to-trip applications in Tricon v10.2+ platforms with high reliability control.
Power Plants: Used for generator set status monitoring and safety shutdown relay control in critical power generation systems.
Substations: Supports bus differential protection, transmission line safeguarding, and switchyard signal acquisition.
Chemical Plants: Provides reliable process automation control with intrinsically safe output signal handling.
Steel Mills / Metallurgical Plants: Ensures stable logic control in high-temperature, high-vibration, and strong EMI environments.
Machinery Manufacturing Plants: Applied in automated production lines, robotic stations, and packaging system control.
Water Treatment & Utilities: Enables distributed I/O control and remote monitoring for pump stations and utility networks.
Food Processing Plants: Supports PLC-based automation for precise coordination between sensors and actuators in production lines.
32-point TMR digital output design
Supports both supervised and non-supervised operation
Compatible with energize-to-trip and de-energize-to-trip logic
Field power grouped in 16-point sections for stability
Compatible with Tricon v10.2+ systems
Enhanced fault detection and diagnostic capability
High reliability for safety-critical applications
Provides high-integrity digital output control in safety instrumented systems
Executes TMR voting logic for fault-tolerant operation
Drives field devices in critical shutdown and control applications
Supports energize-to-trip and de-energize-to-trip safety actions
Monitors output integrity through built-in diagnostics
Ensures system reliability under redundant power conditions
Detects wiring, voter, and field power faults in real time
Maintains stable operation in process safety environments
Q1: What system is Triconex 3625A compatible with?
A1: It is compatible with Tricon systems version 10.2 and later.
Q2: How many output points does the 3625A module support?
A2: It supports 32-point TMR digital outputs.
Q3: Can multiple field power sources be used?
A3: Yes, up to four independent sources, but voltage must be within 5% tolerance.
Q4: What happens if power imbalance occurs?
A4: It may cause voter faults and trigger alarms.
Q5: Is it compatible with older 3625 systems?
A5: Yes, it is fully compatible with 3625 module applications.
Triconex 3625A
TMR Digital Output Module
Safety Instrumented System (SIS)
Tricon v10.2 I/O Module
32-point Output Module
Industrial Automation Control
Redundant Safety System Module
