Product Name:SIMATIC S7/PCS7 digital output module
Brand Name:Siemens
Model Number:6ES7322-8BH10-0AB0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7322-8BH10-0AB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | 6ES7322-8BH10-0AB0, SIMATIC S7/PCS7 SM 322 digital output module, 16-channel 24 V DC control unit |
| Output Type | 16 digital outputs, 24 V DC / 0.5 A per channel for industrial actuator control |
| Diagnostic Function | Wire-break detection, short-circuit monitoring, and channel fault diagnostics |
| Switching Performance | Up to 100 Hz resistive load switching with fast response time |
| Load Voltage | 24 V DC rated, operating range 20.4–28.8 V stable industrial supply |
| Protection Features | Short-circuit protection with 1.4 A response threshold per channel |
| Cable Length | Up to 1000 m shielded, 600 m unshielded for flexible wiring |
| Dimension | 40 × 125 × 120 mm compact modular S7-300 rack-mounted design |
| Weight | Approx. 350 g robust yet lightweight industrial module |
| Mounting | 40-pin front connector with IM 153-X HF interface requirement |
The 6ES7322-8BH10-0AB0 is a SIMATIC S7/PCS7 digital output module from the Siemens automation system portfolio, designed for reliable actuator and load control in industrial environments. It provides 16 digital outputs with 24 V DC / 0.5 A per channel, supporting precise switching performance for distributed control applications.
The 6ES7322-8BH10-0AB0 features advanced diagnostics including wire-break detection for both “0” and “1” signal states, short-circuit protection, and channel-level fault indication. Its robust design ensures stable operation even under inductive and resistive load conditions, making it suitable for safety-critical automation systems.
Engineered for PCS7 and S7-300 architectures, this SM 322 module requires IM 153-X HF connection and delivers high-speed switching with integrated diagnostic feedback. It is widely used in modular automation systems where reliable output control and system transparency are essential.
Q1: What is the main function of 6ES7322-8BH10-0AB0?
A1: It is a digital output module used to control industrial actuators and devices in PLC systems.
Q2: How many output channels does it provide?
A2: It provides 16 independent digital output channels.
Q3: Does it support diagnostics?
A3: Yes, it includes wire-break detection, short-circuit monitoring, and fault indicators.
Q4: What is the output rating per channel?
A4: Each channel supports 24 V DC with a rated current of 0.5 A.
Q5: Where is this module commonly used?
A5: It is widely used in power plants, substations, chemical plants, and industrial automation systems.
|
