Siemens 6ES7334-0CE01-0AA0 ANALOG I/O MODULE

Siemens 6ES7334-0CE01-0AA0 ANALOG I/O MODULE

Product Name: ANALOG I/O MODULE

Brand Name: Siemens

Model Number: 6ES7334-0CE01-0AA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Applications & Use Cases
Product Recommendations
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Siemens 6ES7334-0CE01-0AA0 Analog I/O Module is a multifunction analog module designed for SIMATIC S7 systems, providing both analog input and output capabilities in a single compact unit. It enables the precise measurement of voltage and current signals as well as the generation of analog output signals for controlling industrial actuators, drives, and process equipment.

With support for multiple analog channels and integrated electrical isolation, the module ensures stable signal processing and reliable operation in industrial environments. Its compact design, fast cycle time, and robust Siemens engineering make it suitable for a wide range of automation and process control applications requiring mixed analog signal handling.

Functions

Provides 4 analog input channels for voltage and current measurement.
Supports analog signal acquisition for industrial process monitoring.
Offers 2 analog output channels for controlling actuators and process devices.
Handles voltage and current output signals with protection features.
Converts analog signals into digital values for PLC processing.
Supports fast signal processing with cycle times up to 5 ms.
Includes short-circuit protection on voltage outputs.
Provides electrical isolation tested up to 500 V DC.
Enables integration into SIMATIC S7 backplane communication systems.
Supports both voltage and current-based industrial signal standards.

Specifications

Product Name	Siemens 6ES7334-0CE01-0AA0 ANALOG I/O MODULE
Manufacturer	Siemens
Product Type	ANALOG I/O MODULE
Part Number	6ES7334-0CE01-0AA0
Weight	0.2kg
Estimated shipping dimensions	4x11.6x12.4cm
Place of shipment	Xiamen, China
Country of origin	Germany
Rated value (DC)	24 V
from supply and load voltage L+	110 mA
from backplane bus 5 V DC, max.	55 mA
Power loss, typ	3 W
For voltage measurement	4
permissible input voltage for voltage input	20 V
permissible input current for current input	40 mA
Cycle time (all channels) max.	5 ms
Number of analog outputs	2
Voltage output, short-circuit protection	Yes
Voltage output, short-circuit current, max.	11 mA
Current output, no-load voltage, max.	15 V
Isolation tested with	500 V DC

Advantage

The Siemens 6ES7334-0CE01-0AA0 combines analog input and output functionality in a single module, reducing hardware complexity and improving system efficiency. Compared with separate I/O modules, it offers more compact integration, simplified wiring, and cost-effective system design.

Integrated Analog I/O Functionality

Combines measurement and control functions in one module, reducing system footprint.

Flexible Signal Handling

Supports both voltage and current inputs and outputs for broad application compatibility.

Fast Processing Performance

Cycle times up to 5 ms enable responsive control in dynamic automation systems.

Reliable Industrial Protection

Includes short-circuit protection and 500 V DC electrical isolation for safe operation.

Compact System Integration

Reduces the need for multiple modules, saving space in control cabinets.

Simplified Engineering

Easier configuration and wiring compared to separate analog input and output solutions.

Applications & Use Cases

Industrial process control systems
Machine automation and control loops
Temperature, pressure, and flow monitoring systems
Drive and actuator control applications
Packaging and production machinery
Energy and utility monitoring systems
Water and wastewater treatment plants
Chemical and pharmaceutical process control
Factory automation systems requiring mixed analog signals
Retrofit and expansion of SIMATIC S7 analog I/O systems

This module is ideal for applications requiring both analog measurement and control within a single device, offering a compact and efficient solution for modern industrial automation systems.
