Product Name:Central Processing Unit - AC Power
Brand Name: SIEMENS
Model Number:435-CPU
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
435-CPU |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification (PPX:435-CPU / PPX:435DC-CPU / PPX:435DC1-CPU) |
|
Manufacturer |
Siemens |
|
Model |
TI435-CPU / PPX:435-CPU |
|
Product Family |
SIMATIC TI405 Programmable Logic Controller (PLC) |
|
I/O Points |
640 maximum (320 inputs / 320 outputs) |
|
I/O Module Density |
8, 16, or 32 points per module |
|
Analog I/O Channels |
40 inputs / 20 outputs |
|
Remote I/O Distance |
3300 feet (1000 m) maximum |
|
Remote I/O Points |
512 points |
|
Battery Life |
5 years |
|
Total User Memory |
10.5K words |
|
Ladder Logic Memory |
7.5K words |
|
Variable Memory |
3.0K words |
|
Scan Rate (per 1K Boolean) |
0.49 ms |
|
Programming Language |
Relay Ladder Logic (RLL) and Machine Stage |
|
Instruction Set Size |
174 total instructions |
|
Integer Math |
Yes |
|
Control Relays |
480 total (can utilize unused I/O as CRs) |
|
Special Relays |
62 |
|
Timers / Counters |
128 / 128 (4-digit BCD) |
|
Program Stages |
384 |
|
Subroutines |
Yes (up to 64) |
|
FOR/NEXT Loops |
Yes |
|
Immediate I/O Update |
Yes |
|
Diagnostics |
Built-in, with 98 programmed messages |
|
Security |
Password protection and program name |
|
Communication |
Master/Slave on built-in network port; supports K-sequence and N-sequence protocols |
|
Power Requirement (AC) |
85 to 132 VAC / 170 to 264 VAC, 47 to 63 Hz, 50 VA max, 20 A inrush |
|
Power Supplied |
3700 mA at 5 VDC to base; 400 mA at 24 VDC external (AC version) |
|
Operating Temperature |
0°C to 60°C (32°F to 140°F) |
|
Storage Temperature |
-20°C to 70°C (-4°F to 158°F) |
|
Humidity |
5% to 95%, non-condensing |
|
Agency Approvals |
UL, FCC |
Industrial automation and process control systems
Discrete manufacturing and material handling
Legacy system upgrades and maintenance
Remote I/O monitoring and control
Dual-Language Programming: Supports both Relay Ladder Logic (RLL) and Machine Stage programming.
Built-in Network Port: Enables direct master/slave communication without additional modules.
Extensive I/O Capacity: Supports up to 640 local I/O points and 512 remote I/O points.
High-Speed Processing: Executes 1K boolean instructions in just 0.49 milliseconds.
Powerful Diagnostic Tools: Includes 98 built-in diagnostic messages and user-defined fault messages.
Comprehensive Security: Features password protection and program naming for project security.
Dual-Language Programming: Supports both Relay Ladder Logic (RLL) and Machine Stage programming.
Built-in Network Port: Enables direct master/slave communication without additional modules.
Extensive I/O Capacity: Supports up to 640 local I/O points and 512 remote I/O points.
High-Speed Processing: Executes 1K boolean instructions in just 0.49 milliseconds.
Powerful Diagnostic Tools: Includes 98 built-in diagnostic messages and user-defined fault messages.
Comprehensive Security: Features password protection and program naming for project security.
Program Execution: Executes user-created control programs to manage industrial processes.
System Diagnostics: Monitors CPU, I/O, and communication status, displaying errors via a connected MIU or diagnostic LEDs.
Data Communication: Acts as a master or slave on a network, processing data using K-sequence or N-sequence protocols.
Memory Management: Utilizes a memory cartridge for program storage, supporting CMOS RAM, EEPROM, and UVPROM types.
I/O Control: Reads input signals, executes logic, and updates output states based on the user program.
Q1: What programming software is compatible with the Siemens TI435-CPU?
A1: The TI435-CPU is compatible with TISOFT software running on IBM PC-compatible computers, as well as the PPX:S-10P Machine Interface Unit (MIU) handheld programmer.
Q2: What is the maximum number of I/O points supported by the TI435-CPU?
A2: The TI435-CPU supports up to 640 discrete I/O points (320 inputs and 320 outputs) across up to 4 bases.
Q3: What does the "BATT" LED on the TI435-CPU indicate?
A3: The "BATT" LED illuminates when the CPU's backup battery voltage is low, indicating it needs replacement to maintain memory during power loss.
Q4: Does the TI435-CPU require a memory cartridge?
A4: Yes, unlike the TI425 and TI430 CPUs, the TI435-CPU requires a memory cartridge (CMOS RAM, EEPROM, or UVPROM) for program operation and storage.
Q5: What communication protocols does the TI435-CPU support?
A5: The TI435-CPU supports both K-sequence and N-sequence (Hostlink) protocols, with the V2.1 firmware adding K-sequence support to the bottom (25-pin) serial port.
