Product Name:Communications processor
Brand Name:Siemens
Model Number:6ES7341-1CH02-0AE0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7341-1CH02-0AE0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 6ES7341-1CH02-0AE0 |
| Product Series | SIMATIC S7-300 |
| Product Type | CP 341 Communication Processor |
| Communication Interface | RS422/RS485 |
| Number of Interfaces | 1 Isolated Interface |
| Transmission Rate | 0.3 kbit/s to 115.2 kbit/s |
| Supported Protocols | ASCII, 3964(R), RK512 |
| Maximum Cable Length | 1200 m |
| Connector Type | 15-Pin Sub-D Socket |
| Supply Voltage | 24 V DC |
| Current Consumption | Max. 100 mA |
| Typical Power Loss | 1.6 W |
| Maximum Power Loss | 2.4 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions (W × H × D) | 40 × 125 × 120 mm |
| Weight | Approx. 300 g |
6ES7341-1CH02-0AE0 is a Siemens SIMATIC S7-300 CP 341 communication processor designed to enable reliable point-to-point data exchange between PLC systems and external devices. Equipped with an RS422/485 interface, this module supports industrial communication applications requiring stable serial connectivity, efficient data transmission, and seamless integration with automation networks.
As part of the SIMATIC S7-300 platform, 6ES7341-1CH02-0AE0 supports widely used communication protocols including ASCII, 3964(R), and RK512, providing flexibility for connecting controllers, instrumentation, barcode readers, printers, and third-party equipment. Its isolated communication interface enhances signal integrity and operational reliability.
Widely used in manufacturing, energy, transportation, and process industries, 6ES7341-1CH02-0AE0 helps simplify data exchange, improve system interoperability, and support efficient industrial automation solutions where dependable serial communication is essential.
Power Plants: Enables communication between PLC systems, protection devices, monitoring equipment, and serial communication instruments, ensuring reliable data exchange.
Substations: Supports communication with SCADA systems, intelligent electronic devices, and remote monitoring equipment, improving operational visibility.
Chemical Plants: Integrates process analyzers, weighing systems, barcode devices, and instrumentation into centralized automation networks.
Steel Mills: Facilitates stable serial communication between control systems and production equipment operating in harsh industrial environments.
Machinery Manufacturing Plants: Connects PLCs with HMIs, printers, scanners, and third-party devices, supporting automated production and machine control.
Water Treatment Facilities: Enables communication between controllers, measurement instruments, and supervisory systems, improving process management efficiency.
RS422/RS485 Communication Interface – Supports reliable industrial serial communication, enables long-distance data transmission, enhances system connectivity.
Multi-Protocol Support – Supports ASCII, 3964(R), and RK512 protocols, provides flexible integration with various industrial devices.
Isolated Interface Design – Improves communication stability, reduces electrical interference, enhances operational reliability.
Long Transmission Distance – Supports cable lengths up to 1200 meters, enables communication across large industrial facilities.
Compact S7-300 Integration – Fits seamlessly into SIMATIC S7-300 systems, simplifies installation, supports efficient automation architectures.
Serial Communication Function – Enables data exchange between PLCs and external devices, supports reliable industrial communication applications.
Protocol Conversion Function – Supports multiple communication protocols, facilitates interoperability between different automation components.
Data Transmission Function – Transfers process data, status information, and control commands efficiently across serial networks.
Device Integration Function – Connects printers, scanners, instruments, controllers, and monitoring systems to SIMATIC automation platforms.
Network Expansion Function – Extends communication capabilities of S7-300 PLC systems, improving flexibility and system functionality.
Q1: What is the Siemens 6ES7341-1CH02-0AE0 used for?
A1: It is a CP 341 communication processor used for serial communication between SIMATIC S7-300 PLCs and external devices.
Q2: Which communication interfaces are supported by the module?
A2: The module supports RS422 and RS485 serial communication interfaces.
Q3: What protocols are available on the 6ES7341-1CH02-0AE0?
A3: It supports ASCII, 3964(R), and RK512 communication protocols.
Q4: What is the maximum communication distance supported?
A4: The module supports communication cable lengths of up to 1200 meters under suitable installation conditions.
Q5: Which Siemens PLC family is compatible with this communication processor?
A5: The module is specifically designed for integration with the SIMATIC S7-300 automation platform.
|
