Siemens 6ES7414-2XL07-0AB0 SIMATIC S7-400 CPU 414-2 Central Processing Unit

Siemens 6ES7414-2XL07-0AB0 SIMATIC S7-400 CPU 414-2 Central Processing Unit

Product Name: SIMATIC S7-400 CPU 414-2 Central Processing Unit
Brand Name: Siemens
Model Number: 6ES7414-2XL07-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]

Appurtenance:

siemens 6es7414 2xl07 0ab0 simatic s7 400 cpu 414 2 central processing unit-1

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
Why Choose Us
Other Products
Recommended Products

SIEMENS INDUSTRIAL NETWORKING · SCALANCE XR SERIES

Siemens 6ES7414-2XL07-0AB0 SIMATIC S7-400 CPU 414-2 Central Processing Unit

Industrial Control

Siemens Integrated

Automation System

Official Siemens product data identifies 6ES7414-2XL07-0AB0 as the SIMATIC S7-400 CPU 414-2 Central Processing Unit. The information below is organized for clear industrial sourcing and technical evaluation.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

TECHNICAL PARAMETER	OFFICIAL VALUE
Product type designation	CPU 414-2
HW functional status	01
Firmware version	V7.0
Programming package	STEP 7 V5.4 or higher with HSP 261
CiR synchronization time, basic load	100 ms
CiR synchronization time, time per I/O byte	15 µs
from backplane bus 5 V DC, typ.	0.9 A
from backplane bus 5 V DC, max.	1.1 A
from backplane bus 24 V DC, max.	300 mA; 150 mA per DP interface
from interface 5 V DC, max.	90 mA; At each DP interface
Power loss, typ.	4.5 W
Integrated	2 Mbyte
integrated (for program)	1 Mbyte
integrated (for data)	1 Mbyte
expandable FEPROM, max.	64 Mbyte
integrated RAM, max.	512 kbyte
expandable RAM, max.	64 Mbyte
Backup current, typ.	180 µA; up to 40 °C
Backup current, max.	850 µA
Feeding of external backup voltage to CPU	5 V DC to 15 V DC
for bit operations, typ.	18.75 ns
for word operations, typ.	18.75 ns
for fixed point arithmetic, typ.	18.75 ns
for floating point arithmetic, typ.	37.5 ns
Number of data blocks, max.	6 000; Number range: 1 to 16000
Data block size, max.	64 kbyte
Number of function blocks, max.	3 000; Number range: 0 to 7999
Number of free cycle OBs	1; OB 1
Number of time alarm OBs	4; OB 10-13
Number of delay alarm OBs	4; OB 20-23
Number of cyclic interrupt OBs	4; OB 32-35 (shortest cycle that can be set = 500 µs)
Number of process alarm OBs	4; OB 40-43
Number of DPV1 alarm OBs	3; OB 55-57
Number of isochronous mode OBs	3; OB 61-63
Number of multicomputing OBs	1; OB 60

Contact info

CONTACT

Sales
Jim Pei

Email
[email protected]

Phone/Whatsapp
+86 18020776782

Description

PRODUCT OVERVIEW · 6ES7414-2XL07-0AB0

6ES7414-2XL07-0AB0 is an official Siemens SIMATIC S7-400 CPU 414-2 Central Processing Unit for professional industrial automation. Its verified technical characteristics are summarized from Siemens documentation. The product supports dependable integration into compatible systems. It is suitable for replacement, modernization and engineering review. This Siemens component supports structured industrial sourcing. Our team can assist with model confirmation before shipment.

Function

FUNCTION 01

Executes industrial control programs.

FUNCTION 02

Processes input signals and updates output states.

FUNCTION 03

Communicates with distributed automation devices.

FUNCTION 04

Provides controller and network diagnostics.

FUNCTION 05

Coordinates sequences and interlocks.

FUNCTION 06

Supports engineering and commissioning workflows.

FUNCTION 07

Integrates with Siemens automation architectures.

FUNCTION 08

Provides deterministic industrial control.
