Product Name: SIMATIC S7-400 CPU 414-3
Brand Name: Siemens
Model Number: 6ES7414-3XM05-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6ES7414-3XM05-0AB0 |
| Product type designation | CPU 414-3 |
| HW functional status | 03 |
| Firmware version | V5.3 |
| Programming package | STEP 7 V5.3 SP2 or higher with HW update |
| CiR synchronization time, basic load | 100 ms |
| CiR synchronization time, time per I/O byte | 15 µs |
| 24 V DC | No; Power supply via system power supply |
| from backplane bus 5 V DC, typ. | 1.1 A |
| from backplane bus 5 V DC, max. | 1.3 A |
| from backplane bus 24 V DC, max. | 450 mA; 150 mA per DP interface |
| from interface 5 V DC, max. | 90 mA; At each DP interface |
| Power loss, typ. | 5.5 W |
| Power loss, max. | 6W |
| Type of memory | RAM |
| integrated | 2.8 Mbyte |
| integrated (for program) | 1.4 Mbyte |
| integrated (for data) | 1.4 Mbyte |
| expandable | No |
| expandable FEPROM | Yes; with Memory Card (FLASH) |
| expandable FEPROM, max. | 64 Mbyte |
| integrated RAM, max. | 512 kbyte |
| expandable RAM | Yes; with Memory Card (RAM) |
| expandable RAM, max. | 64 Mbyte |
| present | Yes |
| with battery | Yes; all data |
| without battery | No |
| Backup current, typ. | 125 µA |
| Backup current, max. | 550 µA |
| Backup time, max. | See reference manual, module data, Chapter 3.3 |
| Feeding of external backup voltage to CPU | 5 V DC to 15 V DC |
| for bit operations, typ. | 45 ns |
| for word operations, typ. | 45 ns |
| for fixed point arithmetic, typ. | 45 ns |
| for floating point arithmetic, typ. | 135 ns |
6ES7414-3XM05-0AB0 is an original Siemens SIMATIC S7-400 CPU 414-3 for industrial automation systems. Official product data identifies its electrical, processing, communication, memory, and environmental characteristics for accurate engineering evaluation. The unit is designed for dependable integration within its designated automation platform. It supports reliable machine or process operation, diagnostics, commissioning, maintenance, and system modernization. The product is suitable for replacement projects and lifecycle support where order-number accuracy is essential. This page provides clear sourcing information for the 6ES7414-3XM05-0AB0 industrial automation product.
6ES7414-3XM05-0AB0 is used in industrial control systems that require dependable operation, communication, monitoring, or processing within the designated Siemens automation platform. Typical environments include manufacturing lines, process plants, material handling systems, utilities, and machine automation.
6ES7414-3XM05-0AB0 is suitable for commissioning, diagnostics, scheduled maintenance, spare-parts replacement, and lifecycle extension projects. It helps engineers maintain compatible installations and restore system availability with the correct order number.
