Siemens 6ES7432-1HF00-0AB0 SIMATIC S7-400 SM 432 Analog Output Module

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Model Number	6ES7432-1HF00-0AB0
Analog output channels	8 channels
Output resolution	13 bits including sign and overrange
Load supply voltage	24 V DC
Maximum no-load supply current	200 mA from L+
Maximum supply current at rated load	400 mA from L+
Maximum backplane current	150 mA at 5 V DC
Typical power loss	9 W
Voltage output range, unipolar	0–10 V
Voltage output range, offset	1–5 V
Voltage output range, bipolar	-10 to +10 V
Current output range, unipolar	0–20 mA
Current output range, offset	4–20 mA
Current output range, bipolar	-20 to +20 mA
Maximum voltage-output short-circuit current	30 mA
Maximum current-output no-load voltage	19 V
Minimum voltage-output load resistance	1 kΩ
Maximum voltage-output capacitive load	1 µF
Maximum current-output load	500 Ω; 600 Ω with common-mode voltage <1 V
Maximum shielded cable length	200 m
Settling time, resistive load	0.1 ms
Settling time, capacitive load	3.5 ms
Settling time, inductive load	0.5 ms
Voltage operational error limit	±0.5% of output range
Current operational error limit	±1% of output range
Voltage basic error at 25 °C	±0.5% of voltage output range
Current basic error at 25 °C	±0.5% of ±20 mA / 0–20 mA range
Bus-to-load-supply isolation test	2120 V DC
Bus-to-analog-section isolation test	2120 V DC between bus and analog section
Bus-to-local-ground isolation test	500 V DC
Analog-to-load-supply isolation test	500 V DC between analog section and L+/M
Analog-to-local-ground isolation test	2120 V DC between analog section and local ground
Load-supply-to-ground isolation test	2120 V DC between L+/M and local ground

Contact info

Sales

Jim Pei

Email

[email protected]

Phone/Whatsapp

+86 18020776782

Description

01

Siemens 6ES7432-1HF00-0AB0 is the SIMATIC S7-400 SM 432 analog output module. It provides eight analog output channels for voltage or current signals. The output conversion supports signed values within the documented resolution. The analog section is isolated from the backplane bus and load supply. Channels are not individually isolated from one another.

02

The module connects a compatible S7-400 station to analog field devices. Output ranges must be selected to match the receiving equipment. Field wiring and permissible loads require attention during installation. Voltage and current operation have different load requirements. Check the existing channel configuration before replacing a module.

Diagnostics

01

Diagnostic capability

A built-in diagnostics function is not listed for this module; do not assume channel diagnostic alarms are available.

02

Output-circuit checks

Verify the selected voltage or current mode against the connected field device and permitted load.

03

Isolation arrangement

The analog outputs share a common channel group rather than individual channel-to-channel isolation.

FAQ

01

Are the outputs of 6ES7432-1HF00-0AB0 individually isolated?

No. The analog section is isolated from the bus and load voltage, but the channels are not isolated from each other.

02

Does 6ES7432-1HF00-0AB0 provide a built-in diagnostic function?

No. The data sheet marks the diagnostics function as unsupported.

03

Can 6ES7432-1HF00-0AB0 drive a field device without checking its load?

No. Check the receiver impedance and output mode against the module load requirements.

04

Is 6ES7432-1HF00-0AB0 suitable for both voltage and current signals?

Yes. Use the supported output range and wiring for the intended signal type.

05

Do you check the condition of 6ES7432-1HF00-0AB0 before shipping?

Yes. Each item is tested before delivery; photos and the agreed 12-month warranty are available.

06

What happens after I pay for 6ES7432-1HF00-0AB0?

We immediately arrange dispatch of available stock and send the courier tracking information.
