Siemens 6FC5370-4AM20-0AA0 SINUMERIK 828D BASIC M PPU 240.2 Milling Panel

Siemens 6FC5370-4AM20-0AA0 SINUMERIK 828D BASIC M PPU 240.2 Milling Panel

Product Name: SINUMERIK 828D BASIC M PPU 240.2 Milling Panel

Brand Name: Siemens

Model Number: 6FC5370-4AM20-0AA0

Place of Origin: China

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6fc5370 4am20 0aa0 sinumerik 828d basic m ppu 2402 milling panel-1

Overview
Description
Contact info
Specifications
Commercial Term
FAQ
Other Products
Recommended Products

Match milling software and the installed CNC hardware

This SINUMERIK 828D BASIC M panel processing unit is the vertically arranged PPU 240.2 for milling applications. Siemens lists the hardware order number without system software.

Before you order: Confirm the original panel layout, CompactFlash software and license, drive system and machine backup before a hardware exchange.

Description

Siemens lists the PPU 240.2 BASIC M hardware under 6FC5370-4AM20-0AA0. The corresponding BASIC T turning variant has a different order number, so the intended machining technology must be checked from the approved machine configuration.

Replacing the panel alone does not restore a CNC application. Preserve the original system software, license information, PLC and CNC archives, drive parameters, user data and connected machine-control devices. Commission the replacement under the machine builder's procedure.

Compatibility & Interoperability

Siemens lists this PPU 240.2 among the controls approved for SINAMICS S120 Combi. Verify the exact drive topology and software release used by the machine.

Configuration & Programming

The Siemens ordering table identifies this PPU as hardware without system software; the matching CompactFlash software and license are separate. Preserve the original licensed media.

Installation & Integration

Before removal, document cabinet wiring and connectors, machine control panel connections, network settings and the orientation of the installed operator panel.

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Specifications

Control family

SINUMERIK 828D

Panel processing unit

PPU 240.2 BASIC M

Machine application

Milling

Mounting layout

Vertical operator-panel arrangement

Display class

8.4-inch PPU 240.2 family

Hardware order scope

PPU without system software

Software medium

Matching licensed CompactFlash card required

Drive integration

Check installed SINAMICS configuration

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

FAQ

How do I confirm 6FC5370-4AM20-0AA0 is right for a milling machine rather than a turning machine?

Compare the complete nameplate with the Siemens PPU 240.2 BASIC M ordering table and the machine builder's approved hardware list. The BASIC T turning hardware has a different order number.

What must be backed up before removing 6FC5370-4AM20-0AA0?

Preserve the licensed CompactFlash media, CNC and PLC archives, drive parameters, machine data, network settings and current alarms. Verify the backup can be read before disconnecting the panel.

Why can 6FC5370-4AM20-0AA0 power up without starting the machine application?

Check the required system software and license on the correct CompactFlash card, the machine archive and drive communication. Read the displayed alarms before attempting a fresh load.

Can 6FC5370-4AM20-0AA0 be replaced with a later PPU without engineering work?

Do not assume so. Compare panel cutout, connectors, CNC software, license and SINAMICS compatibility, then follow Siemens and machine-builder migration guidance.

What should I check when 6FC5370-4AM20-0AA0 shows drive communication alarms after exchange?

Inspect the drive network and power, compare restored drive topology and machine data with the approved archive, and review both CNC and drive diagnostics.

What should procurement provide when sourcing 6FC5370-4AM20-0AA0?

Supply the full order number, front and rear nameplate photos, software and license version, machine builder, milling application and whether matching licensed media is available.
