Siemens 6FC5403-0AA20-1AA1 SINUMERIK HT 8 Handheld Terminal with Handwheel

Siemens 6FC5403-0AA20-1AA1 SINUMERIK HT 8 Handheld Terminal with Handwheel

Product Name: SINUMERIK HT 8 Handheld Terminal with Handwheel

Brand Name: Siemens

Model Number: 6FC5403-0AA20-1AA1

Place of Origin: Austria

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6fc5403 0aa20 1aa1 sinumerik ht 8 handheld terminal with handwheel-1

Overview
Contact info
Specifications
Description
Handwheel Setup
Commercial Term
About Company
FAQ
Other Products
Recommended Products

Portable SINUMERIK Operation with Integrated Handwheel

Siemens 6FC5403-0AA20-1AA1 is the SINUMERIK HT 8 handheld terminal version with an integrated handwheel for mobile CNC operation.

Selection checkpoint: Confirm the with-handwheel variant, connection box, machine HMI project, enabling circuit and emergency-stop integration before use.

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Specifications

Technical parameter	Value
Product type designation	SINUMERIK HT 8
Article number	6FC5403-0AA20-1AA1
Version	Handheld terminal with handwheel
Product family	SINUMERIK HT 8
Operator interface	Touch display and hardware controls
Machine controls	Enabling device and emergency-stop device
Supply class	24 V DC handheld terminal system
Lifecycle note	Siemens product phase-out announced
Manufacturer	Siemens

Description

6FC5403-0AA20-1AA1 combines the HT 8 portable operator interface with a handwheel for machine-side CNC setup and service work. The exact suffix distinguishes it from the HT 8 version without a handwheel and must match the machine project and operator workflow.

The handheld terminal participates in machine enabling and emergency-stop functions through the documented connection arrangement. Commissioning must therefore verify the connection box, project assignment, handwheel behavior and the complete machine safety procedure before production release.

Handwheel Setup

01	Portable HMI Operate and observe the SINUMERIK machine close to the work area.

02	Handwheel input Use the integrated handwheel within the configured machine operating mode.

03	Enabling controls Integrate the terminal with the documented enabling and stop circuits.

04	Station changeover Follow the approved connection-box and hot-plug procedure for the machine.

Commercial Term

Quotation	Payment	Lead time	Shipping	Warranty
Contact us for current price and availability	T/T or agreed terms	Confirmed with the quotation	DHL, FedEx, UPS or agreed freight	12 months

About Company

SupplyPLCs supports exact-model review, product-condition confirmation and responsive industrial automation sourcing.

Share the complete order number, installed-system context and destination. Our team will coordinate availability, shipment options and available official product documentation.

FAQ

Q1	How can I confirm that 6FC5403-0AA20-1AA1 is the correct HT 8 version for my machine? Match the complete order number and verify that the machine project expects the integrated handwheel. Also record the connection-box type, cable arrangement and CNC/HMI software context before ordering.

Why can the handwheel on 6FC5403-0AA20-1AA1 remain inactive even though the display is running?

Confirm that the correct machine operating mode, axis selection and project mapping are active before suspecting the terminal. Use SINUMERIK diagnostics to separate a handwheel input issue from an enabling or machine-state interlock.

What should be checked before connecting 6FC5403-0AA20-1AA1 at another operator station?

Use only a station and connection box approved for the machine, then verify the enabling and emergency-stop behavior under the documented changeover procedure. Do not assume that identical-looking connectors provide the same safety function.

How should I respond if 6FC5403-0AA20-1AA1 powers up but does not load the expected operator project?

Check the assigned HT 8 component, HMI software context and connection path against the machine archive. Preserve the working CNC project and diagnose the terminal assignment before performing a project download.

When should 6FC5403-0AA20-1AA1 be removed from service after a cable or impact incident?

Remove it from use if the enclosure, cable, handwheel, enabling device or emergency-stop device is damaged or behaves inconsistently. A normal display does not prove that the complete machine-control and safety paths remain reliable.

Which information should accompany an RFQ for 6FC5403-0AA20-1AA1 during a maintenance outage?

Provide the full order number, connection-box type, cable details, CNC/HMI software version and clear photographs of the terminal and connector. State explicitly that the required version includes the handwheel.
