Siemens 6GK1561-1AA01 SIMATIC NET CP 5611 A2 Communication Processor

Siemens 6GK1561-1AA01 SIMATIC NET CP 5611 A2 Communication Processor

Product Name: Siemens SIMATIC NET CP 5611 A2 Communication Processor

Brand Name: Siemens

Model Number: 6GK1561-1AA01

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Commercial Term
Specifications
Description
Functions
About Company
After-Sales Support
Other Products
Recommended Products

Contact info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Term

Flexible Global Trading

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Official Technical Data

PROFIBUS transfer-rate range	9.6 kbit/s to 12 Mbit/s
Supported rate 1	9.6 kbit/s
Supported rate 2	19.2 kbit/s
Supported rate 3	45.45 kbit/s
Supported rate 4	93.75 kbit/s
Supported rate 5	187.5 kbit/s
Supported rate 6	500 kbit/s
Supported rate 7	1.5 Mbit/s
Supported rate 8	3 Mbit/s
Supported rate 9	6 Mbit/s
Supported rate 10	12 Mbit/s
PCI signal voltage	3.3 V / 5 V
PCI clock frequency	33 MHz / 66 MHz
PCI bus width	32 bit
Maximum backplane current	0.5 A DC
Active power loss	2.5 W
Operating temperature	5 to 55 °C
Storage temperature	-20 to +60 °C
Transport temperature	-20 to +60 °C
Maximum relative humidity	95% at 25 °C, non-condensing
Protection class	IP00
Module width	18 mm
Module height	102 mm
Module depth	130 mm
Net weight	100 g
PROFIBUS electrical connections	1
PROFIBUS connector	9-pin Sub-D female socket
Physical interface	RS-485
Module format	Short PCI card
Host connection	PCI bus
Network connection	PROFIBUS or MPI
Maximum DP slaves	64
DP-slave input data	Up to 122 bytes
DP-slave output data	Up to 122 bytes
DP-slave consistency	Byte consistency
Diagnostic header length	6 bytes
Product type designation	CP 5611 A2
Article number	6GK1561-1AA01
Product lifecycle	Spare part / discontinued
Successor product	CP 5612, 6GK1561-2AA00

Description

6GK1561-1AA01 is the Siemens SIMATIC NET CP 5611 A2 communications processor, built as a 32-bit short PCI card with 3.3/5 V signaling and 33/66 MHz PCI operation. It connects a programming device or industrial PC to PROFIBUS or MPI through one RS-485 interface with transmission rates from 9.6 kbit/s to 12 Mbit/s. The card has a maximum backplane current consumption of 0.5 A, an active power loss of 2.5 W, and an operating range of 5 to 55 °C. This Siemens PROFIBUS PCI communication processor supports dependable engineering, diagnostics, and automation-network access. Its proven SIMATIC NET architecture makes it a practical replacement component for established industrial PC installations. 6GK1561-1AA01 helps preserve communication continuity in legacy PROFIBUS and MPI systems.

Functions

Operational Capabilities

Connects a programming device or PC to PROFIBUS networks.
Provides access to MPI-based SIMATIC automation systems.
Supports engineering and commissioning communication.
Enables cyclic process-data exchange with field devices.
Provides communication services for visualization applications.
Supports diagnostic access to connected automation stations.
Allows PC-based control and supervisory software to reach the fieldbus.
Supports DP master and compatible DP slave communication scenarios.
Integrates legacy PCI industrial computers into SIMATIC networks.
Provides a service replacement path for existing CP 5611 A2 installations.
