Rugged managed Industrial Ethernet switch with eight D-coded M12 ports and redundant power connection.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6GK5208-0HA10-2AA6
|
|
M12 network ports
|
8, D-coded
|
|
Ethernet transfer rates
|
10 / 100 Mbit/s
|
|
Signaling contacts
|
1
|
|
Signaling connector
|
5-pole M12, B-coded
|
|
Power connector
|
4-pole M12, A-coded
|
|
Signaling contact rated voltage
|
24 V DC
|
|
Signaling contact maximum current
|
0.1 A
|
|
Rated supply voltage
|
24 V DC
|
|
Supply voltage range
|
18–32 V DC
|
|
Maximum current consumption
|
0.185 A
|
|
Rated power loss
|
4.4 W
|
|
Input fuse rating
|
0.6 A / 60 V
|
|
Operating temperature
|
-40 to +70 °C
|
|
Storage / transport temperature
|
-40 to +70 °C
|
|
Relative humidity at 25 °C, maximum
|
95%, non-condensing
|
|
Ingress protection
|
IP65 / IP67
|
|
Redundant ring cascade
|
100 devices at <0.3 s reconfiguration
|
|
PROFINET conformity class
|
Class B
|
|
MTBF
|
83 years
|
|
EMC emissions
|
EN 61000-6-4, Class A
|
|
EMC immunity
|
EN 61000-6-2
|
|
Electrical safety
|
UL 60950-1 E115352; CSA C22.2 No. 60950-1
|
|
Supported SNMP versions
|
v1 / v2 / v3
|
|
Media redundancy
|
MRP / HRP with redundancy manager
|
|
Secure management protocols
|
HTTPS / SSH
|
|
Time synchronization protocol
|
SNTP
|
|
Identification-link standard
|
IEC 61406-1:2022
|
|
Network discovery / configuration
|
LLDP / DCP
|
|
DIN mounting rail
|
35 mm
|
|
Removable configuration medium
|
Optional C-PLUG
|
|
Minimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6GK5208-0HA10-2AA6 is the SCALANCE X208PRO managed Industrial Ethernet switch. Eight M12 network connections provide Fast Ethernet links for suitable industrial equipment. The protected housing is designed for the specified demanding environmental conditions. A redundant supply connection and signaling contact support the plant network arrangement. Supported ring redundancy helps maintain communication after an eligible network interruption.
The 6GK5208-0HA10-2AA6 connects distributed industrial devices where rugged field connectors are required. PROFINET IO diagnostics integrates switch information into the engineering workflow. Web management and command-line access provide configuration options. An optional C-PLUG supports the specified configuration storage procedure. Match the connector coding, sealing accessories and network settings to the installed system before replacement.
Connects suitable industrial devices through M12 Ethernet interfaces.
Participates in supported managed ring-redundancy arrangements.
Exposes switch diagnostic information to supported PROFINET engineering.
Configuration storage — Uses the optional C-PLUG for the supported configuration-handling procedure.
Network maintenance — Management and port diagnostics assist fault investigation.
Environmental integration — Maintain connector sealing and the stated operating conditions at installation.
It is listed as optional; confirm whether it is included in the quoted package.
No. Their coding and contact arrangements differ and must be matched correctly.
No. The datasheet identifies PROFINET IO diagnostics but not IRT switch operation.
Yes. Offered-unit photographs and available inspection information can be supplied.
Confirmed stock is arranged for immediate dispatch once payment is received.
Send the existing switch label, ring arrangement and configuration requirements.
