Siemens 6GK5213-3BB00-2AB2 SCALANCE XB213-3 Managed Ethernet Switch

Siemens 6GK5213-3BB00-2AB2 SCALANCE XB213-3 Managed Ethernet Switch

Product Name: SCALANCE XB213-3 Managed Industrial Ethernet Switch

Brand Name: Siemens

Model Number: 6GK5213-3BB00-2AB2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6gk5213 3bb00 2ab2 scalance xb213 3 managed industrial ethernet switch-1

Overview
Details
Connectivity
Monitoring
Specs
Terms
Contact
FAQ
Other Products
Recommended Products

Compact Managed Copper and Fiber Switching

Network role6GK5213-3BB00-2AB2 is a SCALANCE XB213-3 managed Layer 2 switch with thirteen 10/100 Mbit/s RJ45 ports, three 100 Mbit/s multimode ST/BFOC fiber ports and an RJ11 console interface.

Installation checkVerify the exact order number, copper and fiber port map, multimode fiber type and optical budget, 24 V DC supply, PROFINET role, firmware and saved managed configuration before replacement.

Details

6GK5213-3BB00-2AB2 is intended for managed industrial Ethernet and PROFINET networks that need a high copper-port count plus three 100Base-FX multimode links. The RJ11 console port supports local service access.

Before exchange, export the switch configuration and record VLAN, redundancy, multicast, diagnostics, IP and device-name data. Label every RJ45 and optical connection so the topology can be restored without cross-connecting fibers.

Connectivity

Copper, fiber and logical network paths must be documented as one topology before the switch is changed.

Port map

Label all thirteen RJ45 links and three fiber pairs with their connected devices and network role.

Fiber path

Verify multimode fiber, ST/BFOC connectors, transmit and receive pairing and optical distance.

Managed settings

Export VLAN, redundancy, multicast, SNMP, IP and PROFINET device-name configuration.

Monitoring

Use port diagnostics and topology data to distinguish network faults from hardware faults.

Link status

Compare speed, duplex, error counters and optical link state with the documented baseline.

Loop control

Confirm redundancy and spanning-tree settings before reconnecting parallel network paths.

Acceptance test

Verify management access, controller communication, alarms and every production link after replacement.

Specs

Product type designation	SCALANCE XB213-3 managed Layer 2 switch
Order number	6GK5213-3BB00-2AB2
Copper ports	13 × RJ45, 10/100 Mbit/s
Optical ports	3 × multimode ST/BFOC, 100Base-FX
Console connection	1 × RJ11
Supply voltage	24 V DC; permissible 19.2 to 28.8 V
Redundant supply	Supported
Rated power loss	9.8 W
Network role	Managed Layer 2 industrial Ethernet / PROFINET switch
Mounting	DIN rail
Operating temperature	0 to +60 °C
Degree of protection	IP20

Terms

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or freight

Warranty

12 months

Contact

CONTACT	Jim Pei	[email protected]	+86 18020776782

FAQ

Q01

How should I verify that 6GK5213-3BB00-2AB2 is the correct replacement for my switch?

Confirm the XB213-3 order number, thirteen RJ45 ports, three multimode ST/BFOC fiber ports, 24 V DC supply, DIN-rail installation, firmware and required managed network features.

Q02

What should I back up before replacing 6GK5213-3BB00-2AB2?

Export the complete switch configuration and record IP address, PROFINET device name, VLANs, redundancy, multicast, SNMP, port settings, alarms and a labeled copper and fiber topology.

Q03

Why can an optical link stay down after 6GK5213-3BB00-2AB2 is installed?

Verify multimode 100Base-FX compatibility, ST/BFOC connector cleanliness, transmit and receive pairing, fiber continuity, optical budget and the partner port. Review port diagnostics before changing the switch again.

Q04

What should I check if 6GK5213-3BB00-2AB2 passes local traffic but not PROFINET communication?

Confirm the device name and IP settings, VLAN membership, port state, redundancy configuration, controller topology expectations and duplicate addresses. Compare the online topology with the approved project.

Q05

How should I reconnect redundant paths to 6GK5213-3BB00-2AB2 without creating a loop?

Restore the saved redundancy and spanning-tree configuration first, reconnect one path at a time and monitor ring or tree status and port blocking before connecting the final parallel link.

Q06

Which details should I provide when requesting 6GK5213-3BB00-2AB2?

Provide the full order number, firmware, copper and fiber port map, fiber type and distance, supply arrangement, PROFINET role, managed feature configuration and clear label and connector photographs.
