Siemens 6GK5213-3BF00-2AB2 SCALANCE XB213-3LD Managed Ethernet Switch

Siemens 6GK5213-3BF00-2AB2 SCALANCE XB213-3LD Managed Ethernet Switch

Product Name: SCALANCE XB213-3LD Managed Industrial Ethernet Switch

Brand Name: Siemens

Model Number: 6GK5213-3BF00-2AB2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6gk5213 3bf00 2ab2 scalance xb213 3ld managed ethernet switch-1

Overview
Description
Fiber Commissioning
Specifications
Contact info
Commercial Term
About Company
FAQ
Other Products
Recommended Products

Managed Copper and Long-Distance Single-Mode Fiber Networking

Siemens 6GK5213-3BF00-2AB2 is a SCALANCE XB213-3LD managed Layer 2 switch with 13 copper ports and three single-mode SC fiber ports.

Selection checkpoint: Match the XB213-3LD single-mode SC variant, optical link budget, port map, firmware and saved PROFINET network configuration before replacement.

Description

6GK5213-3BF00-2AB2 combines 13 Fast Ethernet RJ45 ports with three long-distance single-mode SC fiber ports in a managed Layer 2 platform. Redundant power input, a console port and PROFINET diagnostics support structured industrial network service.

The BF00 variant is not interchangeable with the BD00 multimode model without checking fiber and link design. Preserve the management address, VLANs, redundancy roles, firmware and every cable destination before moving the installed network to a replacement.

Fiber Commissioning

01	Copper access Connect up to 13 Fast Ethernet field devices through RJ45 ports.

02	Long-distance fiber Use three single-mode SC interfaces for the documented optical links.

03	Managed diagnostics Review port, event and PROFINET information during fault isolation.

04	Configuration continuity Restore VLAN, redundancy and management settings from the approved backup.

Specifications

Technical parameter	Value
Product type designation	SCALANCE XB213-3LD
Article number	6GK5213-3BF00-2AB2
Switch class	Managed Layer 2 Industrial Ethernet switch
Copper interfaces	13 x 10/100 Mbit/s RJ45
Optical interfaces	3 x 100 Mbit/s single-mode SC
Service interface	1 console port
Power supply	Redundant 24 V DC input
Operating temperature	0 to +60 degrees C
Mounting	35 mm DIN rail
Default automation profile	PROFINET
Manufacturer	Siemens

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Commercial Term

Quotation	Payment	Lead time	Shipping	Warranty
Contact us for current price and availability	T/T or agreed terms	Confirmed with the quotation	DHL, FedEx, UPS or agreed freight	12 months

About Company

SupplyPLCs supports exact-model review, product-condition confirmation and responsive industrial automation sourcing.

Share the complete order number, installed-system context and destination. Our team will coordinate availability, shipment options and available official product documentation.

FAQ

How can I confirm that 6GK5213-3BF00-2AB2 matches the switch already used on my single-mode fiber network?

Compare the complete order number, XB213-3LD designation, three SC single-mode ports and 13 RJ45 ports. Confirm the installed fiber type and optical link design before accepting the replacement.

Why can a long-distance optical link stay down after 6GK5213-3BF00-2AB2 is installed?

Verify single-mode fiber, SC connector condition, transmit/receive pairing, partner-interface type and optical budget. Use the switch diagnostics to isolate the affected path before changing VLAN or redundancy settings.

How should I preserve the network configuration before replacing 6GK5213-3BF00-2AB2?

Export or document the approved configuration, including management address, VLANs, redundancy roles, PROFINET identity and port settings. Label all 13 copper and three optical links before disconnecting the old switch.

What should I check if 6GK5213-3BF00-2AB2 forwards local traffic but the redundant ring will not close?

Compare the configured ring ports and redundancy role with the network design, then inspect both optical paths and partner settings. Avoid connecting an undocumented loop while the active topology is uncertain.

Q5	How should I test the redundant power inputs of 6GK5213-3BF00-2AB2 after cabinet service? Verify both 24 V feeds, terminal polarity and alarm indication independently under the approved procedure. Confirm that loss of either feed is reported without interrupting the intended network service.

Q6	Which details should accompany an RFQ for 6GK5213-3BF00-2AB2? Provide the exact order number, firmware, optical fiber type and destinations, copper port map, management address and redundancy role. These records distinguish the long-distance single-mode model from multimode XB213-3 variants.
