Siemens 6GK5308-2GG00-2AA2 SCALANCE X308-2M Managed Industrial Ethernet Switch

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Model Number	6GK5308-2GG00-2AA2
Integrated copper ports	4 × RJ45, 10/100/1000 Mbit/s
Media-module positions	2 positions for two-port electrical or optical modules
Media-module data rates	100 / 1000 Mbit/s
Rated supply voltage	24 V DC
Permissible supply voltage	18–32 V DC
Maximum current consumption	0.7 A
Rated power loss	16.6 W
Power connection	4-pole terminal block
Input fuse	F 3 A / 32 V
Signaling contact terminal	1 × 2-pole terminal block
Signaling contact rated voltage	24 V DC at contact
Signaling contact current limit	0.1 A
Operating temperature, base device	-40 to +70 °C; module-dependent derating applies
Operating temperature with SFPs	-40 to +60 °C
Maximum temperature, vertical mounting	+50 °C
Storage / transport temperature	-40 to +70 °C
Maximum relative humidity	95% at 25 °C, non-condensing
Ingress protection	IP20
DIN rail size	35 mm; not permitted for shipbuilding installation
Redundant ring capacity	100 devices at reconfiguration time <0.3 s
PROFINET conformity	Class B
Maximum VLANs	255 VLANs, including up to 255 dynamic VLANs
SNMP versions	v1 / v2 / v3
DHCP options	66 / 67 / 82
Identification levels	I&M0 / I&M1
Spanning-tree protocols	STP / RSTP / MSTP
Ring redundancy protocols	MRP / HRP with redundancy manager
Link aggregation protocol	LACP
Authentication	IEEE 802.1X / RADIUS
Multicast management	IGMP snooping / querier; GMRP
Secure management	HTTPS / SSH
Time synchronization	NTP / SNTP / IEEE 1588 default profile
Safety standards	UL 60950-1 / CSA C22.2 No. 60950-1
MTBF	40 years

Contact info

Sales

Jim Pei

Email

[email protected]

Phone/Whatsapp

+86 18020776782

Description

01

Siemens 6GK5308-2GG00-2AA2 is the SCALANCE X308-2M managed Industrial Ethernet switch. It combines integrated Gigabit copper connections with media-module positions. The media modules provide the required electrical or optical connection arrangement. A signaling contact and select/set pushbutton support local operation. C-PLUG is included in the stated scope of supply.

02

The switch supports managed machine and plant communication networks. Network segmentation and multicast management are available within the documented capabilities. Supported redundancy procedures allow engineered network recovery arrangements. Remote management and traffic diagnostics assist maintenance. The installed media and mounting orientation affect the permitted operating environment.

Diagnostics

01

Traffic observation

Port and multiport mirroring are available for observing selected network traffic.

02

Statistics and events

Packet statistics, error statistics and SysLog provide different views of network behavior.

03

Remote monitoring

PROFINET IO diagnostics, SNMP and RMON support management of the configured installation.

FAQ

01

Are all network connections built into 6GK5308-2GG00-2AA2?

No. It combines built-in copper ports with positions for separately selected media modules.

02

Is C-PLUG optional for 6GK5308-2GG00-2AA2?

The specified product description includes C-PLUG in the scope of supply; confirm the actual quoted package.

03

Does vertical mounting change the limits for 6GK5308-2GG00-2AA2?

Yes. Follow the orientation and installed-media temperature restrictions in the data sheet.

04

Can 6GK5308-2GG00-2AA2 mirror more than one port?

Yes. Both port mirroring and multiport mirroring are listed.

05

Can I check the actual 6GK5308-2GG00-2AA2 and its accessories?

Yes. We confirm the supplied items and condition with photos, test before delivery and provide the agreed 12-month warranty.

06

Will you release 6GK5308-2GG00-2AA2 as soon as payment clears?

Yes, available stock is dispatched promptly after payment is received, with courier tracking.
