Siemens 6GK5416-4GR00-2AM2 SCALANCE XM416-4C Managed Industrial Ethernet Switch

Siemens 6GK5416-4GR00-2AM2 SCALANCE XM416-4C Managed Industrial Ethernet Switch

Product Name: SCALANCE XM416-4C Managed Industrial Ethernet Switch

Brand Name: Siemens

Model Number: 6GK5416-4GR00-2AM2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
Why Choose Us
Other Products
Recommended Products

Siemens 6GK5416-4GR00-2AM2 SCALANCE XM416-4C Managed Industrial Ethernet Switch

The Siemens 6GK5416-4GR00-2AM2 is a managed modular Industrial Ethernet switch with electrical, optical and combo-port connectivity for high-performance automation networks.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

Ethernet transmission rate	10/100/1,000 Mbit/s
RJ45 electrical ports	16
SFP optical ports	4
Combo ports	4
Integrated switch ports	20
Extender interfaces	2
Rated supply voltage	24 V DC
Permissible supply voltage range	19.2–28.8 V DC
Typical current consumption	0.1 A
Maximum current consumption	2 A
Maximum PoE output per port	30 W
Maximum total PoE output	180 W
Maximum power loss	48 W
PoE standard	IEEE 802.3at
PoE-capable ports	8
C-PLUG support	Yes
Redundant power supply inputs	2
Digital signaling contact	1
Signaling contact load	24 V DC / 0.1 A
Operating temperature range	−40–70 °C
Storage/transport temperature range	−40–85 °C
Maximum relative humidity	95 %
Protection rating	IP20
Maximum VLANs	256
Maximum VLAN IDs	4,094
MAC address table	8,000 entries
Maximum multicast groups	1,000
PROFINET IO diagnosis	Supported
MRP media redundancy	Supported
RSTP support	IEEE 802.1D-2004
Link aggregation	IEEE 802.3ad
Quality of Service	IEEE 802.1Q / 802.1p
SNMP versions	v1 / v2c / v3
Web-based management	HTTP / HTTPS
Time synchronization	SNTP

Contact info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Description

6GK5416-4GR00-2AM2 is a Siemens SCALANCE XM416-4C managed Industrial Ethernet switch designed for reliable communication in demanding industrial networks. Its electrical, optical and combo interfaces support flexible plant connectivity and modular expansion. Official Siemens management functions provide diagnostics, redundancy and structured configuration. This Siemens industrial network switch is suitable for machine, cell and backbone architectures. It helps build scalable and maintainable automation networks. Amikon supplies original industrial automation components with responsive commercial and technical support.

Function

Connects controllers, HMIs and industrial network devices.

Provides managed switching for structured automation networks.

Supports optical and electrical Ethernet connections.

Enables redundant network topologies for increased availability.

Provides VLAN-based segmentation of industrial traffic.

Supports network diagnostics and remote management.

Prioritizes time-critical automation communications.

Allows modular expansion through compatible extender interfaces.
