Siemens 6GK5874-3AA00-2AA2 SCALANCE M874-3 Industrial Router

Siemens 6GK5874-3AA00-2AA2 SCALANCE M874-3 Industrial Router

Product Name: SCALANCE M874-3 3G Industrial Router

Brand Name: Siemens

Model Number: 6GK5874-3AA00-2AA2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6gk5874 3aa00 2aa2 scalance m874 3 3g industrial router-1

Overview
Description
Cellular Integration
Specifications
VPN Diagnostics
Contact info
Commercial Term
FAQ
Other Products
Recommended Products

Industrial 3G HSPA+ router with VPN, firewall and NAT for remote Ethernet automation networks

SCALANCE M874-3 connects Ethernet devices over cellular HSPA+ and combines a two-port switch with routing, VPN, firewall, NAT, digital input and digital output functions. Cellular service, antenna design and the complete security configuration must be verified before deployment.

Cellular service and VPN checkConfirm regional 3G service and approvals, SIM card, APN, antenna and signal path, 24 V supply, Ethernet addressing, firewall and NAT rules, VPN certificates and remote-management settings. Siemens lists this model as discontinued.

Description

6GK5874-3AA00-2AA2 is the SCALANCE M874-3 industrial mobile router for connecting Ethernet automation equipment through GSM and UMTS HSPA+ networks. It provides two 10/100 Mbit/s RJ45 ports, one digital input, one digital output and security functions for controlled remote access.

Before replacement, export the router configuration and preserve SIM, APN, IP, NAT, firewall, VPN, user and certificate information. Confirm that the destination country and mobile operator still support the required 3G bands and service before planning a like-for-like exchange.

Cellular Integration

Network service, SIM provisioning and the complete antenna path determine whether the router can register reliably.

Service check

Confirm supported 3G bands, destination-country approval and ongoing operator service before shipment.

SIM and APN

Record SIM format, PIN policy, APN, credentials, roaming limits and expected public or private addressing.

Antenna path

Verify SMA connection, 50-ohm antenna system, cable loss, lightning protection and safe clearance.

Specifications

Product type designation

SCALANCE M874-3

Order number

6GK5874-3AA00-2AA2

Cellular service

GSM / UMTS with HSPA+

Ethernet

2 x RJ45, 10/100 Mbit/s

Antenna connection

1 x SMA, nominal 50 ohms

Security

Stateful firewall, NAT/NAPT and VPN functions

Management / diagnostics

WBM, CLI, LEDs, logging and SNMP

Digital I/O

1 digital input and 1 digital output

Supply

24 V DC terminal connection

Installation

Wall, DIN rail, S7-300 rail, S7-1500 rail or 19-inch frame options

Lifecycle

Discontinued; regional cellular support must be checked

Weight

Approximately 0.377 kg

VPN Diagnostics

Preserve security evidence and test the connection from cellular registration through the protected application path.

Registration

Check SIM status, signal quality, mobile-network registration and assigned IP address before VPN diagnosis.

Tunnel setup

Verify time, certificates, peer address, authentication, routes and firewall rules on both tunnel endpoints.

Application path

Test the required service through the VPN and confirm NAT, return routing and blocked traffic behavior.

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

FAQ

How can I confirm that 6GK5874-3AA00-2AA2 will operate in the destination country?

Check the local approvals, supported GSM and UMTS bands and whether the mobile operator still provides compatible 3G service. Confirm SIM, APN, roaming and antenna requirements before dispatch because the model is discontinued.

What settings should be saved before replacing 6GK5874-3AA00-2AA2?

Export the router configuration and preserve APN, SIM policy, Ethernet addresses, routes, NAT and firewall rules, VPN profiles, certificates, users, digital I/O settings and a copy of relevant logs.

Why can 6GK5874-3AA00-2AA2 detect the SIM but fail to establish a data session?

Verify SIM activation and PIN, APN and credentials, roaming permission, cellular bands, antenna connection and signal quality. Review mobile-network and system logs before changing the VPN configuration.

How should the antenna for 6GK5874-3AA00-2AA2 be installed?

Use a compatible 50-ohm antenna on the SMA connector, minimize cable loss and follow the required user clearance. For outdoor antennas, implement the full site lightning-protection and grounding concept rather than relying only on an inline protector.

What should be checked when the VPN on 6GK5874-3AA00-2AA2 remains down?

First confirm cellular registration and IP connectivity, then check device time, peer reachability, certificates or keys, authentication, tunnel proposal, routes and firewall rules. Compare both endpoints and retain the failure log.

How should 6GK5874-3AA00-2AA2 be commissioned after replacement?

Install and ground the router, connect the approved antenna and SIM, restore the reviewed configuration on an isolated path and verify cellular registration. Then test VPN, NAT, required application traffic, alarm I/O and blocked traffic before production release.
