Siemens 6GK7342-5DA02-0XE0 SIMATIC S7-300 CP 342-5 communication processor In stock

Siemens 6GK7342-5DA02-0XE0 SIMATIC S7-300 CP 342-5 communication processor In stock

Product Name:SIMATIC S7-300 CP 342-5 communication processor

Brand Name:Siemens

Model Number:6GK7342-5DA02-0XE0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6gk7342 5da02 0xe0 simatic s7 300 cp 342 5 communication processor in stock-1

Overview
Inquiry now
Specifications
Description
Applications
Enviromental Strength
Features and benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6GK7342-5DA02-0XE0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6GK7342-5DA02-0XE0
Product Series	SIMATIC S7-300 CP 342-5
Product Type	PROFIBUS Communication Processor
Communication Interface	1 × PROFIBUS RS485 (9-pin Sub-D)
Transmission Rate	9.6 kbit/s to 12 Mbit/s
PROFIBUS Function	DP Master / DP Slave
Maximum DP Slaves	124
Maximum S7 Connections	16
Open Communication	Up to 16 SEND/RECEIVE connections
Supply Voltage	24 VDC
Power Consumption	Approx. 5 W
Protection Rating	IP20
Configuration Software	STEP 7 V5.1 SP2 or later
Operating Temperature	0°C to +60°C
Dimensions	40 × 125 × 120 mm
Weight	Approx. 0.30 kg

Description

6GK7342-5DA02-0XE0 is a SIMATIC S7-300 CP 342-5 communication processor engineered to connect Siemens PLC systems with PROFIBUS DP networks for reliable industrial data exchange. It supports high-speed communication up to 12 Mbit/s while enabling efficient integration between controllers, distributed I/O devices, HMIs, and engineering stations.

Designed for demanding automation environments, 6GK7342-5DA02-0XE0 works seamlessly with SIMATIC S7-300, CP 343-1, and other Siemens communication modules to expand networking capabilities without increasing CPU workload. The module supports S7 communication, PROFIBUS DP master/slave functionality, and S5-compatible PG/OP communication, making it suitable for both legacy system upgrades and new automation projects.

With compact dimensions, flexible installation, stable data transmission, and compatibility with STEP 7 engineering software, 6GK7342-5DA02-0XE0 provides a dependable communication solution for manufacturing plants, process industries, energy facilities, and machine builders requiring secure and high-performance PROFIBUS networking.

Applications

Power plants: Used for PLC communication between turbine controllers, generator monitoring systems, and PROFIBUS field devices.
Substations: Enables reliable data exchange for protection relays, remote I/O stations, and electrical automation systems.
Chemical plants: Connects distributed process controllers with PROFIBUS instrumentation for continuous production control.
Steel mills: Provides stable industrial communication in environments affected by vibration, dust, and electromagnetic interference.
Machinery manufacturing plants: Integrates PLCs, drives, HMIs, and distributed I/O for automated production lines and intelligent equipment.
Water treatment facilities: Supports centralized communication between pumps, valves, sensors, and SCADA systems.

Enviromental Strength

Industrial-grade operating temperature from 0°C to +60°C for continuous production environments.
Storage temperature range of −40°C to +70°C for safe transportation and warehousing.
Supports operation in environments with up to 95% relative humidity (non-condensing).
IP20 enclosure designed for installation inside industrial control cabinets.
Compact S7-300 module minimizes cabinet space requirements.
Built for long-term stable communication in industrial automation systems.
Designed according to Siemens industrial reliability standards.
Suitable for factory automation, process control, and infrastructure applications.

Features and benefits

Fast PROFIBUS communication improves overall production efficiency.
Supports both legacy S5 communication and modern S7 networking.
Compatible with a wide range of Siemens S7-300 hardware.
Easy integration using STEP 7 engineering software.
Reduces communication bottlenecks in distributed automation systems.
Flexible DP Master and DP Slave operating modes.
Stable long-term operation with low maintenance requirements.
Ideal for system expansion, modernization, and industrial network upgrades.

FAQ

Q1: What is the primary function of the 6GK7342-5DA02-0XE0?
A1: The 6GK7342-5DA02-0XE0 is a PROFIBUS communication processor designed to connect SIMATIC S7-300 PLCs with PROFIBUS DP networks, enabling stable, high-speed industrial data communication.

Q2: Does the 6GK7342-5DA02-0XE0 support both DP Master and DP Slave modes?
A2: Yes, the module supports both PROFIBUS DP Master and DP Slave operating modes, allowing flexible integration into various industrial automation architectures.

Q3: What is the maximum PROFIBUS transmission speed of the 6GK7342-5DA02-0XE0?
A3: The communication processor supports PROFIBUS transmission rates ranging from 9.6 kbit/s up to 12 Mbit/s for fast and reliable network performance.

Q4: Which engineering software is compatible with the 6GK7342-5DA02-0XE0?
A4: The module is configured using Siemens STEP 7 V5.1 SP2 or later, providing efficient setup, diagnostics, and communication management.

Q5: Which industrial applications commonly use the 6GK7342-5DA02-0XE0?
A5: The 6GK7342-5DA02-0XE0 is widely used in manufacturing, power generation, water treatment, chemical processing, transportation, and other industrial automation systems requiring dependable PROFIBUS communication.
