Siemens 6GT2002-0JE10 SIMATIC RF RF185C RFID Communication Module

Siemens 6GT2002-0JE10 SIMATIC RF RF185C RFID Communication Module

Product Name: SIMATIC RF RF185C RFID Communication Module

Brand Name: Siemens

Model Number: 6GT2002-0JE10

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6gt2002 0je10 simatic rf rf185c rfid communication module-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The Siemens 6GT2002-0JE10 SIMATIC RF RF185C RFID Communication Module is a versatile RFID communication module designed for seamless integration with SIMATIC industrial automation systems. It features PROFINET and Industrial Ethernet connectivity, RS422/RS232 reader interfaces, 100 Mbit/s Ethernet communication, support for one RFID reader, and an IP67-rated enclosure for reliable operation in demanding industrial environments. Designed to provide efficient RFID data communication and device connectivity, the module enhances traceability, simplifies system integration, and improves production efficiency. Its broad compatibility with Siemens RFID and identification systems makes it an ideal solution for manufacturing, logistics, material handling, assembly lines, and industrial tracking applications.

Specifications

Product Name	Siemens 6GT2002-0JE10 SIMATIC RF RF185C RFID Communication Module
Manufacturer	Siemens
Product Type	SIMATIC RF RF185C RFID Communication Module
Part Number	6GT2002-0JE10
Place of shipment	Xiamen, China
Country of origin	Germany
Rated Supply Voltage	24 VDC
Permissible Supply Voltage	20.4–28.8 VDC
Typical Current Consumption	0.13 A at 24 VDC (without connected devices)
Maximum Supply Current	4 A
Maximum Loop-Through Current	12 A
Operating Temperature	-25 to +55 °C
Storage Temperature	-40 to +70 °C
Transport Temperature	-40 to +70 °C
Degree of Protection	IP67
Shock Resistance	300 m/s² (IEC 60068-2-27 / IEC 60068-2-6)
Vibration Resistance	40 m/s²
Supported Systems	RF200, RF300, RF1000, MV300, MV400, MV500
Supported Networks	PROFINET, Industrial Ethernet, EtherNet/IP, OPC UA
Number of Connectable Readers	1
Industrial Ethernet Transfer Rate	100 Mbit/s
Serial Transfer Rate	Up to 921.6 kbit/s
Reader Interface	RS422 / RS232
Industrial Ethernet Connector	M12, D-coded
Supply Voltage Connector	M12, L-coded
Reader Communication Connector	M12, 8-pin
Housing Material	Thermoplastic (Valox 467, fiberglass reinforced)
Maximum Mounting Screw Torque	3 N·m
Status Indicators	2 LEDs per reader connection, 3 device status LEDs, 2 Ethernet port LEDs
Programming Support	ID Profile, Function Library, FB45, OPC UA, XML
Communication Functions	Acyclic Communication, Process Image Communication, TCP/IP
Certifications	CE, FCC, cULus, PNO Conformance Class B, Netload Class (SL1) III, OPC UA Embedded UA Server Profile
MTBF	70 years

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

Comprehensive RFID System Compatibility
Supports Siemens RF200, RF300, RF1000, MV300, MV400, and MV500 identification systems, providing flexible integration across a wide range of industrial RFID applications.

Flexible Industrial Network Connectivity
Supports PROFINET, Industrial Ethernet, EtherNet/IP, and OPC UA, enabling reliable communication with modern industrial automation and digital manufacturing systems.

High-Speed Data Exchange
Provides fast Ethernet communication and high-speed serial data transfer, ensuring efficient RFID data acquisition and timely communication between field devices and controllers.

Rugged Industrial Design
Features an IP67-rated housing with excellent shock and vibration resistance, delivering dependable performance in harsh manufacturing and production environments.

Advanced Diagnostics and Programming Support
Includes comprehensive LED status indicators and supports multiple programming tools and communication functions, simplifying commissioning, diagnostics, and system maintenance.

Ideal for Industrial Identification Applications
Well suited for production traceability, assembly automation, warehouse logistics, conveyor systems, material handling, and other industrial applications requiring reliable RFID communication.

FAQ

Q1: What is the 6GT2002-0JE10 used for?
A: The 6GT2002-0JE10 is an RFID communication module used to connect Siemens RFID readers with industrial automation networks for identification and data exchange.

Q2: Which industrial networks does the 6GT2002-0JE10 support?
A: The 6GT2002-0JE10 supports PROFINET, Industrial Ethernet, EtherNet/IP, and OPC UA, enabling flexible integration into industrial automation systems.

Q3: Which RFID systems are compatible with the 6GT2002-0JE10?
A: The 6GT2002-0JE10 is compatible with Siemens RF200, RF300, RF1000, MV300, MV400, and MV500 identification systems.

Q4: Is the 6GT2002-0JE10 suitable for harsh industrial environments?
A: Yes. The 6GT2002-0JE10 features an IP67 protection rating and rugged construction for reliable operation in demanding industrial conditions.

Q5: What communication interfaces are available on the 6GT2002-0JE10?
A: The 6GT2002-0JE10 provides RS422/RS232 interfaces for RFID readers together with Industrial Ethernet connectivity for reliable communication with automation controllers.

Q6: Which industrial applications are suitable for the 6GT2002-0JE10?
A: The 6GT2002-0JE10 is widely used in manufacturing, logistics, assembly lines, conveyor systems, material handling, warehouse automation, and industrial traceability applications requiring dependable RFID communication.
