Product Name:Analog Output Module
Brand Name:Honeywell
Model Number:8C-PAON01 51454357-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-PAON01 51454357-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 8C-PAON01 / 51454357-175 |
| Type | Analog Output Module |
| Output Signal | 4–20 mA DC |
| Channels | 16 |
| IOTA Compatibility | 8C-TAOX51 / 8C-TAOX61 |
| Redundancy | Supported (via redundant IOTA) |
| Resolution | ±0.05% Full Scale |
| Accuracy | ±0.35% @ 25°C |
| Response Time | ≤80 ms settling time |
| Open Circuit Voltage | Max 22 V |
| Dimension | 152 mm (6 in) / 304 mm (12 in redundant setup) |
| Weight | ~0.8 kg (module only) |
| Operating Temp | 0°C to 60°C |
| Protection | Conformal coated (industrial grade) |
The 8C-PAON01 51454357-175 Analog Output Module is designed for precise 4–20 mA signal control in modern distributed control systems. As part of the Series 8 I/O family, it works alongside models such as 8C-PAOH51, 8C-PAON01, and related IOTA assemblies to ensure stable actuator and instrumentation output in industrial environments.
This module provides 16-channel high-level analog output with both standard and redundant configurations supported through compatible IOTA bases like 8C-TAOX51 and 8C-TAOX61. Its architecture integrates signal conditioning and field power distribution directly within the IOTA framework, reducing external wiring complexity.
Built for demanding process automation, the 8C-PAON01 51454357-175 ensures reliable performance, fast response, and diagnostic-driven operation. It is widely used in control loops requiring stable analog output for valves, drives, and process instrumentation.
Q1: What is the main function of 8C-PAON01?
A1: It provides 16-channel 4–20 mA analog output for industrial control applications.
Q2: Does 8C-PAON01 support redundancy?
A2: Yes, redundancy is available when used with compatible IOTA configurations.
Q3: What systems is it compatible with?
A3: It integrates with Series 8 control systems and IOTA bases like 8C-TAOX51 and 8C-TAOX61.
Q4: What output range does it support?
A4: It delivers standard 4–20 mA DC output signals for field devices.
Q5: Is fault detection included?
A5: Yes, it supports open-wire detection and channel-level diagnostics.
| Number (I/O Module Coated) | Description |
|---|---|
| 8C-PAIH51 | High-level AI HART |
| 8U-PAIH51 | High-level AI HART |
| 8C-PAIN01 | High-level AI w/o HART |
| 8U-PAIN01 | High-level AI w/o HART |
| 8C-TAIX51 | AI IOTA, Coated |
| 8U-TAIX51 | AI IOTA, Uncoated |
| 8C-TAIX61 | AI IOTA Redundant, Coated |
| 8U-TAIX61 | AI IOTA Redundant, Uncoated |
| 8C-PAIM01 | PMIO LL Mux |
| 8U-PAIM01 | PMIO LL Mux |
| MC-TAMT04 | LL Mux TC FTA |
| MC-TAMR04 | LL Mux RTD FTA |
| 8C-PAOH51 | Analog Output 16pt HART |
| 8U-PAOH51 | Analog Output 16pt HART |
| 8C-PAON01 | Analog Output 16pt w/o HART |
| 8U-PAON01 | Analog Output 16pt w/o HART |
| 8C-TAOX51 | AO IOTA, Coated |
| 8U-TAOX51 | AO IOTA, Uncoated |
| 8C-TAOX61 | AO IOTA Redundant, Coated |
| 8U-TAOX61 | AO IOTA Redundant, Uncoated |
| 8C-PDIL51 | Digital Input 24V |
| 8U-PDIL51 | Digital Input 24V |
| 8C-TDIL51 | DI 24V IOTA, Coated |
| 8U-TDIL51 | DI 24V IOTA, Uncoated |
| 8C-TDIL61 | DI 24V IOTA Redundant, Coated |
| 8U-TDIL61 | DI 24V IOTA Redundant, Uncoated |
