Siemens 6SE7036-5GK84-1JC2 SIMOVERT MASTERDRIVES IGD8 Module

Siemens 6SE7036-5GK84-1JC2 SIMOVERT MASTERDRIVES IGD8 Module

Product Name: SIMOVERT MASTERDRIVES IGD8 Inverter Control Module

Brand Name: Siemens

Model Number: 6SE7036-5GK84-1JC2

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Overview
Safety
Details
Specs
Upgrade
Terms
Contact
FAQ
Other Products
Recommended Products

Legacy IGD8 Control for High-Current MASTERDRIVES

Application6SE7036-5GK84-1JC2 is an IGD8 inverter control module for SIMOVERT MASTERDRIVES units in the 860 A and 1580 A converter classes, with 500-690 V three-phase AC or 675-930 V DC applications.

Exact-match reviewTreat this as a revision-sensitive spare. Verify the converter type and serial number, voltage and current class, board revision, connector layout and Siemens service documentation. The product is discontinued; migration planning should consider LV SINAMICS.

Safety

High-voltage converter service requires controlled isolation, discharge and verification before board access.

Stored energy

Follow the converter waiting time and verify absence of voltage at the specified test points.

ESD control

Use grounded ESD protection and handle the module only by approved edges and service points.

Release process

Complete drive diagnostics and a controlled low-risk functional test before returning the load to production.

Details

6SE7036-5GK84-1JC2 is not a general-purpose drive option; it is an internal control and gate-drive service module for selected high-current MASTERDRIVES assemblies. Similar boards can differ in power-stage compatibility and commissioning data.

Work inside the converter requires qualified personnel, verified isolation and discharge and ESD protection. Record every connector and fiber path, preserve the installed parameter set and investigate the original failure cause before energizing a replacement.

Specs

Product type designation	SIMOVERT MASTERDRIVES IGD8 inverter control module
Order number	6SE7036-5GK84-1JC2
Product role	Spare internal inverter control / gate-drive module
Applicable AC device range	500 to 690 V three-phase AC, 50/60 Hz
Applicable DC device range	675 to 930 V DC
Referenced current classes	860 A and 1580 A
Lifecycle status	Discontinued; Siemens migration path to LV SINAMICS
Replacement basis	Exact converter, serial number, current class and board revision
Commissioning requirement	Restore and verify converter-specific parameters and diagnostics
Safety requirement	Qualified service with isolation and stored-energy discharge
Official listed net weight	Approximately 0.36 kg
Packaging dimensions	Approximately 69 × 16 × 6 cm

Upgrade

Because the module is discontinued, repair strategy should include the complete converter lifecycle.

Installed-base review

Document the converter type, serial number, power rating, options and available tested spares.

Migration scope

Assess motor, encoder, control interfaces, fieldbus, braking and cabinet requirements before a SINAMICS migration.

Recovery plan

Maintain verified parameter backups and define whether board repair, converter exchange or staged modernization is appropriate.

Terms

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or freight

Warranty

12 months

Contact

CONTACT	Jim Pei	[email protected]	+86 18020776782

FAQ

Q01

How should I verify that 6SE7036-5GK84-1JC2 matches my MASTERDRIVES converter?

Compare the complete converter and module order numbers, device serial number, 500 to 690 V AC or 675 to 930 V DC class, 860 A or 1580 A rating, board revision and every connector position.

Q02

What should I back up before replacing 6SE7036-5GK84-1JC2?

Archive the complete converter parameter set, option and communication settings, active and historical faults and commissioning records. Photograph all connectors, fibers, jumpers and board labels before removal.

Q03

Why can the converter remain inhibited after 6SE7036-5GK84-1JC2 is installed?

Read the converter diagnostics, then check module seating, connector and fiber pairing, auxiliary supplies, enable chain, parameter consistency and power-stage feedback. Do not bypass a protective interlock.

Q04

What should I inspect if 6SE7036-5GK84-1JC2 fails again shortly after replacement?

Investigate the power stage, gate connections, auxiliary supplies, cooling, contamination, insulation and load-side fault history. A repeated board failure can indicate an unresolved converter or motor problem.

Q05

How should I plan a migration when 6SE7036-5GK84-1JC2 is no longer available?

Document the full drive, motor, encoder, fieldbus, I/O, braking and cabinet interfaces and obtain a Siemens-engineered SINAMICS migration study. Validate process performance and downtime requirements before conversion.

Q06

Which details should I provide when requesting 6SE7036-5GK84-1JC2 as a service spare?

Provide the full module and converter order numbers, serial number, voltage and current class, board revision, parameter backup, fault history and clear photographs of the labels and connector layout.
