Siemens 6SL3040-1MA01-0AA0 SINAMICS S120 CU320-2 PN Control Unit

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Model Number	6SL3040-1MA01-0AA0
Rated electronics supply	24 V DC
Permissible electronics supply	20.4–28.8 V DC
Maximum electronics current	1 A, excluding digital outputs, option slot and DRIVE-CLiQ supply
Maximum power loss	24 W
Isolated digital inputs	12 inputs
Digital input voltage	-3 to +30 V
Digital input low level	-3 to +5 V
Digital input high level	15–30 V
Typical input current at 24 V	3.5 mA per digital input
Typical digital-input rising delay	50 µs
Bidirectional digital I/O	8 non-isolated channels
Fast I/O input rising delay	5 µs
Fast I/O input falling delay	50 µs
Digital output voltage	24 V DC at digital output
Maximum current per digital output	500 mA
Output rising delay	150 µs typical / 400 µs maximum
Output falling delay	75 µs typical / 100 µs maximum
DRIVE-CLiQ connections	4 connections
RS-232 connections	1 serial connection
Service Ethernet connections	1 Ethernet interface
Measuring sockets	3 measuring sockets
CompactFlash slots	1 card slot
Option-module slots	1 expansion slot
PE connection	1 × M5 screw
Installation altitude	2000 m
Operating temperature	0 to +55 °C
Storage temperature	-25 to +55 °C
Transport temperature	-40 to +70 °C
Maximum transport relative humidity	95% at 40 °C
Maximum supply conductor cross-section	2.5 mm²
Maximum digital I/O conductor cross-section	1.5 mm²
Maximum fuse protection	20 A
Automation network	PROFINET / EtherNet/IP
PROFINET connections	2 ports

Contact info

Sales

Jim Pei

Email

[email protected]

Phone/Whatsapp

+86 18020776782

Description

01

Siemens 6SL3040-1MA01-0AA0 is the SINAMICS S120 CU320-2 PN Control Unit. It provides the PROFINET control-unit configuration for a compatible drive system. DRIVE-CLiQ connections link the control unit to supported drive components. Digital inputs and bidirectional digital I/O provide local control signals. The electronics require a DC power supply.

02

The control unit coordinates the configured drive system through the selected engineering project. A CompactFlash card holds the required firmware configuration. The option-module slot supports an appropriate expansion arrangement. Service interfaces are available for the specified commissioning workflow. Check firmware, card and drive-component compatibility before replacing an existing unit.

Diagnostics

01

Network configuration

Check the PROFINET configuration and the control unit target selected in the engineering project.

02

Drive-component links

Review the connected DRIVE-CLiQ arrangement against the configured drive components.

03

Firmware identification

Confirm the CompactFlash firmware and compatible control-unit configuration when investigating commissioning issues.

FAQ

01

Is 6SL3040-1MA01-0AA0 the PROFIBUS control-unit configuration?

No. This is the CU320-2 PN configuration. Select the required fieldbus using the complete order number.

02

What firmware is required for 6SL3040-1MA01-0AA0?

The Siemens CU320-2 catalog specifies a CompactFlash card with firmware V4.4 or later for the PN unit.

03

Can 6SL3040-1MA01-0AA0 be ordered without clarifying its CompactFlash card?

Confirm the card, firmware and included items before ordering; do not assume they are included with the control unit.

04

Are local digital outputs of 6SL3040-1MA01-0AA0 protected against short circuits?

The CU320-2 catalog lists the digital outputs as continuously short-circuit proof; the permitted load still applies.

05

Can I inspect the supplied 6SL3040-1MA01-0AA0 configuration?

Yes. We can provide label photos and package details. Items are tested before delivery and carry the agreed 12-month warranty.

06

How quickly is 6SL3040-1MA01-0AA0 released after payment?

Available stock is dispatched immediately upon payment receipt, and courier tracking is supplied.
