Product Name:single-channel module
Brand Name:Siemens
Model Number:7MH4601-1AA01
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
7MH4601-1AA01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 7MH4601-1AA01 |
| Product Type | SIWAREX U weighing module |
| Function | Load cell signal processing & weight measurement |
| System Compatibility | SIMATIC / SIWAREX U platform |
| Supply Voltage | 6 V load cell excitation (typical) |
| Communication Ports | RS232 / TTY interface |
| Baud Rate | 9600 bit/s fixed |
| Configuration Tool | SIWATOOL U software |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5%–95% non-condensing |
| Dimension | 120 × 80 × 62 mm (approx.) |
| Weight | 0.35–0.6 kg (approx.) |
| Mounting Type | DIN rail / control cabinet installation |
The 7MH4601-1AA01 is a high-precision industrial weighing and process interface module designed within the SIWAREX U system. It is widely used for accurate load cell signal processing, providing stable and reliable weight measurement in automated industrial environments.
The 7MH4601-1AA01 module ensures seamless communication with SIMATIC-based control systems via flexible configuration tools and function block integration. It supports precise signal acquisition, limit value processing, and real-time monitoring, making it suitable for advanced weighing and control applications.
Engineered for long-term industrial use, the 7MH4601-1AA01 delivers robust performance with high compatibility across system upgrades. It maintains consistent operation even in demanding environments, while supporting RS232/TTY communication, configurable LED status indication, and integration with SIWATOOL U software for parameter management and system diagnostics.
Q1: What is the main function of 7MH4601-1AA01?
A1: It is used for precise weight measurement and load cell signal processing in industrial systems.
Q2: Is 7MH4601-1AA01 compatible with newer SIWAREX modules?
A2: Yes, it is compatible with newer versions like 7MH4950-*AA01.
Q3: What software is used for configuration?
A3: The module is configured using SIWATOOL U software.
Q4: Does it support communication with SIMATIC systems?
A4: Yes, it supports SIMATIC CPU communication via function blocks.
Q5: Can it be used as a replacement module?
A5: Yes, it is designed as a direct replacement for older SIWAREX U modules.
