Product Name:Logic Module
Brand Name: SIEMENS
Model Number:6ED1052-1MD08-0BA2
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
6ED1052-1MD08-0BA2 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Manufacturer |
Siemens |
|
Product Type |
LOGO! 12/24RCE Logic Module (Basic Device) |
|
Order Number |
6ED1052-1MD08-0BA2 |
|
Product Family |
LOGO! 8.4 |
|
Display |
Yes, with backlight, 4 lines × 12 characters |
|
Mounting |
35 mm DIN rail, 4 spacing units wide |
|
Supply Voltage (DC) |
12 V DC / 24 V DC |
|
Permissible Range (DC) |
10.8 … 28.8 V DC |
|
Digital Inputs |
8 |
|
Digital Inputs Configurable as Analog (0–10 V) |
4 |
|
Digital Outputs |
4, relay type |
|
Output Current (Signal "1", 0 … 55 °C) |
max. 10 A |
|
Switching Capacity (resistive load) |
max. 10 A |
|
Switching Capacity (inductive load) |
max. 3 A |
|
ShortCircuit Protection |
No; external fusing necessary |
|
Memory Capacity |
400 function blocks |
|
Time Switching Clocks |
max. 400 (functionspecific) |
|
RealTime Clock Power Reserve |
480 h |
|
Ethernet Interface |
1 × RJ45 (10/100 Mb/s) |
|
Web Server |
Integrated |
|
Data Logging |
Standard (via microSD card) |
|
MicroSD Card Slot |
1 × standard microSD |
|
Cloud Connection |
Yes (AWS, Azure, Alibaba, general MQTT broker) |
|
MQTT Protocol Support |
Yes (all LOGO! 8.4 basic units) |
|
HTTPS/TLS Encryption |
Yes |
|
Programming Software |
LOGO! Soft Comfort V8.4 or higher |
|
Expandability |
Up to 24 DI / 20 DO / 8 AI / 8 AO |
|
Protection Rating |
IP20 |
|
Operating Temperature |
–20 °C … +55 °C (no condensation) |
|
Storage / Transport Temperature |
–40 °C … +70 °C |
|
Altitude (during operation) |
–1000 m … +2000 m |
|
Dimensions (W × H × D) |
71.5 × 90 × 60 mm |
|
Net Weight |
approx. 0.27 kg |
|
Certifications |
CE, UL, FM, Marine (in preparation), VDE 0631, IEC 61131 |
|
Radio Interference Suppression |
EN 55011 Limit Class B (residential / light commercial) |
|
Environmental Product Declaration |
Yes |
|
Global Warming Potential (total) |
51.5 kg CO₂ equivalent |
|
RoHS Compliant |
Yes |
|
Country of Origin |
CN |
The Siemens 6ED1052-1MD08-0BA2 is an advanced LOGO! 8.4 logic module with integrated display. Operating on 12/24 V DC, the 6ED1052-1MD08-0BA2 provides eight digital inputs (four configurable as 0–10 V analog inputs) and four relay outputs rated up to 10 A. With 400‑block memory, Ethernet, integrated web server, microSD card slot, and native MQTT cloud support, the Siemens 6ED1052-1MD08-0BA2 delivers powerful yet user‑friendly automation for building, machinery, and IoT applications.
Building automation: lighting control, blinds, shutters, heating and ventilation (HVAC)
Machine control: small machinery automation, conveyor belt systems, bending machines
Pump and motor control: sequencing, level monitoring and irrigation systems
Access systems: gate, door and garage automation
Remote monitoring and control: via integrated web server and MQTT cloud connectivity
Elevator safety: speed sensor comparison and slip detection
400‑block memory and 8 digital inputs (4 configurable as 0–10 V analog inputs)
4 relay outputs with 10 A switching capacity (resistive load)
Integrated display with backlight for local operation and diagnostics
Built‑in Ethernet port with integrated web server for remote access and monitoring
Native cloud connectivity supporting AWS, Azure, Alibaba and general MQTT broker
Standard microSD card slot for data logging, program storage and firmware updates
HTTLER/TLS encryption for secure cloud connection
Modular expandability: up to 24 DI / 20 DO / 8 AI / 8 AO via expansion modules
Wide operating temperature range: –20 °C to +55 °C (no condensation)
EN 55011 Limit Class B certification permits installation in residential and light commercial environments
Timer functions: on‑delay, off‑delay, on/off‑delay, weekly/yearly timer, pulse generator
Counter functions: up/down counter, hours counter, threshold trigger
Analog functions: comparator, threshold trigger, amplifier, differential trigger
Basic logic: AND, OR, XOR, NAND, NOT, edge evaluation
Special functions: latching relay, pulse relay, shift register, message texts, softkey
Cloud connectivity: MQTT publish/subscribe via LOGO! 8.4 engineering software
Remote monitoring: integrated web server with user‑defined web pages
Data logging to microSD card with CSV‑compatible format for analysis
Email sending: supports customized email notifications at trigger events
Variable memory extension: VX area and VR area for retentive data storage
Ethernet communication: peer‑to‑peer networking with up to nine LOGO! 8 modules or SIMATIC S7 systems
Q1: What is the Siemens 6ED1052-1MD08-0BA2 used for?
A1: A compact logic module for small‑scale automation tasks including building lighting control, pump sequencing, gate automation, and IoT‑ready remote monitoring.
Q2: Does the 6ED1052-1MD08-0BA2 support MQTT and cloud connectivity?
A2: Yes. All LOGO! 8.4 basic units, including 6ED1052-1MD08-0BA2, support MQTT and connect to AWS, Azure, Alibaba IoT Cloud or any general MQTT broker.
Q3: What software is required to program the Siemens 6ED1052-1MD08-0BA2?
A3: LOGO! Soft Comfort V8.4 or higher. The software runs under Windows, Linux and Mac OS.
Q4: Can the Siemens 6ED1052-1MD08-0BA2 be expanded?
A4: Yes. The module is modularly expandable with digital (DM8, DM16) and analog (AM2) expansion modules, up to 24 DI, 20 DO, 8 AI and 8 AO.
Q5: What is the output current rating of the 6ED1052-1MD08-0BA2 relays?
A5: Maximum 10 A per relay on resistive loads (e.g. lamps, heaters) and up to 3 A on inductive loads (e.g. motors, solenoid valves). External fusing is required.
