SIEMENS SIMATIC ET 200SP 6ES7193-6BP00-0BA0 BaseUnit BU15-P16+A0+2B | Original New

SIEMENS SIMATIC ET 200SP 6ES7193-6BP00-0BA0 BaseUnit BU15-P16+A0+2B | Original New

SIEMENS · SIMATIC ET 200SP 6ES7193-6BP00-0BA0 BaseUnit BU15-P16+A0+2B	BASEUNIT 15 MM BU type A0
Connection: Push-in terminals · Order check: Match the complete article number and installed-system configuration.

Overview
Applications
Technical Data
Interfaces
Environment
Installation
Availability
Recommended Models
FAQ & Quote
Recommended Products

OFFICIAL PRODUCT OVERVIEW

6ES7193-6BP00-0BA0 BaseUnit BU15-P16+A0+2B

The Siemens SIMATIC ET 200SP BaseUnit 6ES7193-6BP00-0BA0 is the BU15-P16+A0+2B terminal base for selected ET 200SP I/O modules. It provides 16 process terminals, push-in connection technology, no AUX terminals and a new potential group fed from the left.

Applications

SYSTEM ROLE

Where it is used

Mechanical and electrical field-wiring base for a compatible ET 200SP I/O module. Use it where a 15 mm BaseUnit, BU type A0 and left-fed potential group are required.

Technical Data

OFFICIAL DATA

Technical Data

Width: 15 mm
Process terminals: 16
Connection: Push-in
P1/P2 current: max. 10 A
Process terminal current: max. 2 A
Dimensions: 15 × 117 × 35 mm
Weight: approx. 40 g

Interfaces

CONSTRUCTION

Interfaces

The BaseUnit provides the module slot, process-terminal row and potential-group contacts. It has no AUX or additional terminals. Verify the plugged I/O module permits BU type A0 before ordering.

Environment

OPERATING LIMITS

Environment

Horizontal installation: -30 to 60 °C. Vertical installation: -30 to 50 °C. Operation up to 5000 m is subject to Siemens altitude restrictions above 2000 m.

Installation

BEFORE COMMISSIONING

Installation

Confirm BU type A0, 15 mm width, terminal assignment, potential-group boundary and the exact ET 200SP I/O module. Follow the Siemens system manual for wiring, conductor preparation and removal.

Availability

COMMERCIAL CHECK

Availability

Availability: Confirm before quotation.
Condition: New, used or refurbished status is stated on the quotation.
Current photos and nameplate: Available on request.
Warranty and dispatch: Subject to verification.
Testing: Test scope is stated on the quotation.
Payment methods and quote response: Available on request.
Transaction record: Company and banking details can be supplied for verification.

Recommended Models

RELATED SIEMENS PARTS

Recommended Models

6ES7193-6BP20-0BA0	6ES7193-6BP00-0DA0	6ES7193-6BP20-0DA0	6ES7193-6BP00-0BA1
6ES7131-6BF01-0BA0	6ES7132-6BF01-0BA0	6ES7134-6GD01-0BA1	6ES7135-6HD00-0BA1
6ES7155-6AU01-0CN0	6ES7193-6PA00-0AA0	6ES7193-6PA00-0BA0	6ES7193-6AR00-0AA0
6ES7137-6AA00-0BA0	6ES7138-6BA01-0BA0	6ES7138-6DB00-0BB1	6ES7193-6BP40-0BA1
6ES7193-6BP60-0DA0	6ES7193-6BP00-0DA0	6ES7155-6MU00-0CN0	6ES7193-6BP20-0BA1

FAQ & Quote

COMMON QUESTIONS

FAQ and request quote

Is this exact article number available?
Availability is confirmed before quotation. Send the complete model, required quantity and destination.

Can I receive current photos and a test statement?
Yes, both are available on request and remain subject to the quoted unit and agreed test scope.

What should be supplied for a compatibility check?
Complete article number 6ES7193-6BP00-0BA0 · Compatible I/O module · BU type A0 · Potential-group layout · Current unit photo and nameplate available on request.
