SIEMENS | SIMATIC S7-1500
6ES7521-1BL10-0AA0
DI 32x24 V DC BA Digital Input Module
|
32 DI
DIGITAL INPUT
|
OFFICIAL PRODUCT OVERVIEW
A 32-channel S7-1500 input module with two groups and an included push-in connector.
DI 32x24 V DC BA Digital Input Module for SIMATIC S7-1500. Technical selection must follow the official Siemens data for the complete article number.
|
32 DI
Model: 6ES7521-1BL10-0AA0
Condition and stock status: Subject to verification.
|
|
Channels
|
32 digital inputs
|
|
Grouping
|
2 groups of 16
|
|
Input delay
|
Typ. 3.2 ms
|
|
Supply
|
19.2 to 28.8 V DC
|
|
Signal 1 current
|
Typ. 2.7 mA
|
|
Power loss
|
Typ. 3 W
|
|
Dimensions
|
25 x 147 x 129 mm
|
|
Weight
|
Approx. 260 g
|
|
Signal type
|
24 V DC digital input
|
|
Input characteristic
|
IEC 61131 Type 3
|
|
Front connector
|
40-pole push-in connector included
|
|
Signal 0 range
|
-30 to +5 V
|
|
Signal 1 range
|
+11 to +30 V
|
|
Firmware
|
V1.0.0; update supported
|
|
Protection
|
Confirm in official product data
|
|
Operating temperature
|
Confirm in official product data
|
|
Storage temperature
|
Confirm in official product data
|
|
Humidity
|
Confirm in official product data
|
|
Backplane power
|
1.05 W
|
|
Supply range
|
19.2 to 28.8 V DC
|
|
01
|
Confirm S7-1500 CPU, rack and firmware compatibility.
|
|
02
|
Check the two groups of 16 against the intended potential arrangement.
|
|
03
|
Verify the included 40-pole push-in connector scope.
|
|
04
|
Confirm field wiring, sensor current and cabinet clearance before ordering.
|
|
Article number
|
6ES7521-1BL10-0AA0
|
|
System
|
Confirm CPU, rack and engineering configuration
|
|
Accessories
|
Confirm connectors and separately ordered parts
|
|
Electrical data
|
Match field voltage, current and channel arrangement
|
|
Documentation
|
Request current datasheet or official manual when required
|
|
Visual evidence
|
Current unit and nameplate photos available on request
|
|
Stock status
|
Confirm before quotation
|
|
Condition
|
Subject to verification
|
|
Current photos
|
Available on request
|
|
Warranty
|
Confirm before quotation
|
|
Dispatch time
|
Subject to verification
|
|
Testing
|
Available on request and according to agreed scope
|
|
Payment methods
|
Confirm before quotation
|
|
Quote response
|
Subject to verification
|
|
Company and trade documents
|
Available on request
|
|
