6ES7522-1BL01-0AB0 DQ 32x24 V DC/0.5 A HF Digital Output Module

Siemens 6ES7522-1BL01-0AB0 is the SIMATIC S7-1500 SM 522 digital output module DQ 32x24 V DC/0.5 A HF. It provides 32 transistor outputs arranged in groups of eight, with diagnostics and switching-cycle counters.

Applications

SYSTEM ROLE

Where it is used

For high-density 24 V DC actuator control in S7-1500 systems, including solenoid valves, contactor interfaces, indicator circuits and other binary loads within the official channel ratings.

Technical Data

OFFICIAL DATA

Technical Data

Outputs: 32 channels
Output rating: 24 V DC / 0.5 A
Groups: 4 groups of 8
Maximum per group: 4 A
Diagnostics: Single-channel capable
Dimensions: 35 × 147 × 129 mm
Weight: approx. 280 g

Interfaces

CONSTRUCTION

Interfaces

The module uses the S7-1500 backplane bus and a removable front connector. The front connector is ordered separately. Verify load type, shared commons, group current and protective wiring.

Environment

OPERATING LIMITS

Environment

Rated 24 V DC supply range is 19.2 to 28.8 V DC. Typical module loss is approximately 3.5 W. Apply the official S7-1500 ambient, EMC and cabinet-clearance limits.

Installation

BEFORE COMMISSIONING

Installation

Confirm front-connector availability, group the loads within current limits and configure diagnostics, substitute values and switching-cycle counters in the project before commissioning.

Availability

COMMERCIAL CHECK

Availability

Availability: Confirm before quotation.
Condition: New, used or refurbished status is stated on the quotation.
Current photos and nameplate: Available on request.
Warranty and dispatch: Subject to verification.
Testing: Test scope is stated on the quotation.
Payment methods and quote response: Available on request.
Transaction record: Company and banking details can be supplied for verification.
