Product Name:DC Input Module
Brand Name: SIEMENS
Model Number:505-4232A
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
505-4232A |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The Siemens 505‑4232A is a 32‑point discrete AC input module for the SIMATIC 505/TI 505 platform. Each of the 32 channels accepts 110 VAC field signals (79–132 VAC range) and optically isolates them from the controller. The 505‑4232A consumes only 2 W from the backplane. With configurable 6–30 ms input filtering and four isolated input commons, the 505‑4232A securely connects push buttons, limit switches and other AC field devices to the PLC logic.
Factory automation – Assembly lines, packaging machinery, material handling
Process control – Chemical, pharmaceutical, food & beverage production
Water/wastewater treatment – Pump monitoring, valve position feedback
Building automation – HVAC equipment status, lighting control
Legacy system retention – Direct replacement in existing 505‑based control racks
High channel density – 32 AC inputs in a single‑wide module
Accepts 110 VAC signals (79–132 VAC operating range)
4 isolated commons (8 inputs per common)
Integrated input delay filter (6–30 ms, configurable)
Optical isolation protects the PLC backplane from field transients
Low power consumption (2 W from 505 backplane)
Built‑in per‑point LED status indication
Rack‑mount design with single‑wide form factor
Converts 110 VAC ON/OFF field signals into logic‑level states that the 505 CPU can read
Filters input transients with a 6–30 ms delay to suppress electrical noise
Optically isolates each input channel to protect controller electronics from field voltage spikes
Organises 32 input points into four isolated commons (8 points per common)
Illuminates individual channel LEDs to provide real‑time visual status of the field inputs
Receives power directly from the 505 backplane, requiring no external supply
Q1: What is the input voltage range for the 505‑4232A?
A1: The 505‑4232A accepts AC signals from 79 VAC to 132 VAC, with a nominal rating of 100–115 VAC.
Q2: How many input points does the 505‑4232A have?
A2: The 505‑4232A provides 32 discrete AC input points.
Q3: What is the power consumption of the 505‑4232A?
A3: It consumes 2 W from the 505 backplane and requires no external power supply.
Q4: Is the 505‑4232A still in production?
A4: No, it is discontinued. However, new‑old‑stock and refurbished units remain available from industrial automation suppliers.
Q5: Can the 505‑4232A be used with a modern PLC?
A5: It is designed for the 505 platform. When used with a 505‑compatible rack, it can be controlled by a modern CTI 2500‑series CPU.
