YOKOGAWA VF702 Control Bus Interface Card Original new

YOKOGAWA VF702 Control Bus Interface Card Original new

Product Name:Control Bus Interface Card

Brand Name:YOKOGAWA

Model Number:VF702

Country of Origin:Japan

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

yokogawa vf702 control bus interface card original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	YOKOGAWA
Model Number:	VF702
Country of Origin:	Japan
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	VF702 Control Bus Interface Card designed for V net communication via PCI Express interface in industrial automation systems.
Interface Type	PCI Express x1 compliant card, compatible with x1 to x16 slots for flexible industrial PC integration.
Communication Protocol	10BASE-2 coaxial bus transmission supporting stable and long-distance industrial control network communication.
Connector Type	Dual BNC connectors designed for T-type coaxial bus structure with terminator compatibility.
Max Transmission Distance	Supports up to 185 m transmission distance using standard 10BASE-2 coaxial cable for reliable signal integrity.
Power Supply	3.3 V ±9% PCI Express power input ensuring stable operation in industrial computing environments.
Current Consumption	Maximum 2.4 A under full load conditions, suitable for continuous industrial communication tasks.
Dimension	22 × 126.5 × 193.54 mm compact structure designed for standard industrial PC chassis installation.
Weight	Approximately 0.15 kg lightweight design for easy handling and system integration in control cabinets.

Description

The VF702 Control Bus Interface Card is designed to provide reliable communication between a PC/AT-compatible system and the V net control network. Installed via a PCI Express slot, it enables stable industrial data exchange for distributed automation environments.

The VF702 supports seamless integration with existing VF701 systems, allowing mixed-node operation within the same control bus architecture. It is fully compatible with V net domain and station addressing methods, ensuring flexible system expansion and maintenance.

Equipped with BNC-based 10BASE-2 communication and status indication LEDs, the VF702 delivers efficient signal monitoring and transmission, making it suitable for industrial control platforms requiring robust and continuous network connectivity.

Applications

Power Plants: Used for generator set monitoring, system synchronization, and relay protection signal communication.
Substations: Enables bus differential control, switchyard data acquisition, and protection relay networking.
Chemical Plants: Supports process automation systems and safe distributed signal communication.
Steel Mills (Metallurgical Plants): Provides reliable control bus operation in high-temperature and EMI-intensive environments.
Machinery Manufacturing Plants: Applied in automated production lines, robotics control systems, and packaging equipment networks.

Features

PCI Express-based V net control bus interface card
Dual BNC connectors supporting 10BASE-2 communication
LED indicators for transmit (SND) and receive (RCV) status
Compatible with VF701 for mixed system operation
Compact industrial-grade PCB design

Functions

Converts PCIe signals into V net control bus communication
Supports stable data transmission between PC systems and field control networks
Enables domain and station addressing configuration
Provides real-time communication status monitoring via LED indicators
Ensures reliable integration into industrial automation architectures
