Product Name: PWA, SEI SENSOR ELECT.INTE
Brand Name: ABB
Model Number: 086364-001
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB 086364-001 PWA, SEI Sensor Electronic Interface Module is an industrial signal interface board designed for acquiring and processing analog sensor signals in automation systems. It provides 8 input channels supporting both 0–10 V DC voltage signals and 4–20 mA current signals, making it suitable for a wide range of industrial sensors. With a 12-bit resolution and 500 V AC isolation between input and output, the module ensures accurate signal acquisition and reliable operation in demanding control environments.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB 086364-001 PWA, SEI SENSOR ELECT.INTE |
| Manufacturer | ABB |
| Product Type | PWA, SEI SENSOR ELECT.INTE |
| Part Number | 086364-001 |
| Weight | 0.14 kg |
| Estimated shipping dimensions | 12.6x8.9x4.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Number of Inputs | 8 |
| Resolution | 12-bit |
| Mounting Type | DIN rail |
| Operating Temperature | -20 to +60 °C |
| Connection Type | Screw terminal |
| Weight | Approximately 0.5 kg |
| Input Voltage Range | 0 to 10 V DC |
| Input Current Range | 4 to 20 mA |
| Dimensions | 100 mm x 120 mm x 20 mm |
| Isolation | 500 V AC (input to output) |
| Compliance | CE, UL, and other relevant standards |
Dual Signal Compatibility
The 086364-001 supports both voltage and current inputs, allowing flexible integration with a wide range of industrial sensors.
High Signal Resolution
With 12-bit resolution, the module provides more precise signal measurement compared to lower-resolution interface boards.
Strong Electrical Isolation
The 500 V AC isolation improves system safety and reduces the risk of electrical interference between input and output circuits.
Flexible Industrial Installation
DIN rail mounting and compact dimensions make installation simple and space-efficient in control cabinets.
Reliable ABB Engineering Quality
Designed according to ABB industrial standards, the module ensures stable performance and long service life in automation systems.
The ABB 086364-001 PWA, SEI Sensor Electronic Interface Module is designed for industrial control cabinet installation and operates within a temperature range of -20°C to +60°C. It is powered through standard industrial control system wiring and supports DIN rail mounting for secure installation. The module is suitable for use in environments compliant with CE and UL standards. For optimal performance, it should be installed in a clean, dry, and well-ventilated enclosure, protected from excessive moisture, dust, vibration, and electromagnetic interference.
Q1: What isolation level does ABB 086364-001 provide?
The ABB 086364-001 provides 500 V AC isolation between input and output circuits.
Q2: What input signals does ABB 086364-001 support?
The ABB 086364-001 supports 0–10 V DC voltage signals and 4–20 mA current signals.
Q3: How many input channels does ABB 086364-001 have?
The ABB 086364-001 provides 8 analog input channels.
Q4: What is the resolution of ABB 086364-001?
The ABB 086364-001 has a 12-bit resolution for signal conversion.
Q5: What type of mounting is used for ABB 086364-001?
The ABB 086364-001 is designed for DIN rail mounting in control cabinets.
Q6: Why is ABB 086364-001 used in industrial systems?
The ABB 086364-001 is widely used due to its dual signal compatibility, high measurement resolution, strong electrical isolation, and reliable performance in industrial automation applications.
