Product Name:Printed circuit board
Brand Name:ABB
Model Number:1SFA899301R1007 PSPCB-CB-1 1SFB536268D1007
Country of Origin:SWEDEN
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
1SFA899301R1007 PSPCB-CB-1 1SFB536268D1007 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 1SFA899301R1007 / PSPCB-CB-1 / 1SFB536268D1007 |
| Product Type | Control Printed Circuit Board |
| Manufacturer | ABB |
| Product Series | PSTX Softstarter Series |
| Compatible Softstarters | PSTX30 – PSTX170 |
| Board Type | Control Board 1 |
| Function | Softstarter electronic control processing |
| Application Role | Motor starting control system board |
| Material | Industrial-grade electronic PCB |
| Electrical Function | Signal processing & control interface |
| Installation Type | Internal softstarter module |
| Maintenance | Non-serviceable field replacement unit |
| Dimensions (Approx.) | 120 × 80 × 25 mm (4.72 × 3.15 × 0.98 in.) |
| Weight | 0.65 kg |
| Operating Temperature | Industrial standard softstarter environment |
| Storage Temperature | -40°C to 85°C |
| Compliance | IEC / ABB internal standards |
1SFA899301R1007 / PSPCB-CB-1 / 1SFB536268D1007 is a dedicated control printed circuit board designed for ABB PSTX softstarter systems, providing reliable electronic control functions for stable motor starting performance. It is engineered to ensure precise signal processing and efficient coordination within softstarter control architectures.
As part of the ABB PSTX platform, PSPCB-CB-1 (1SFA899301R1007) is specifically developed for PSTX30 to PSTX170 softstarter ranges. Related control board versions such as PSPCB-CB-2 and PSPCB-CB-3 extend compatibility to higher power PSTX models, ensuring full system scalability across different motor sizes.
The 1SFA899301R1007 / PSPCB-CB-1 is widely used in industrial motor control applications where stable operation, protection, and reliable electronic switching are required, supporting long-term performance in demanding automation environments.
Power Plants: Used for generator auxiliary motor starting control and relay coordination systems.
Substations: Supports motor-driven switchgear control and auxiliary system automation.
Chemical Plants: Ensures safe motor soft-start control in process automation environments.
Steel Mills: Provides stable motor control under high-temperature and high-interference conditions.
Machinery Manufacturing Plants: Applied in automated production lines, pumps, compressors, and conveyor motor control systems.
Q1: What is the function of 1SFA899301R1007 PSPCB-CB-1?
A1: It is a control PCB used inside ABB PSTX softstarters for motor control processing.
Q2: Which softstarter models are compatible with this board?
A2: It is compatible with PSTX30 to PSTX170 softstarter units.
Q3: Can PSPCB-CB-1 be used in higher power PSTX models?
A3: No, higher power models require PSPCB-CB-2 or PSPCB-CB-3 boards.
Q4: Is this board replaceable in the field?
A4: Yes, it is designed as an internal replaceable module in the softstarter.
Q5: What industries commonly use this control board?
A5: It is widely used in power plants, chemical plants, steel mills, and industrial motor control systems.
