Product Name: NSV Probe
Brand Name: Bently Nevada
Model Number: 330905-00-08-10-02-CN
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Alternative Name
Bently Nevada 3300 NSv Proximity Probe
3300 XL NSv Eddy Current Probe
M10×1 Industrial Proximity Sensor Probe
Compact NSv Vibration Monitoring Probe
3300 NSv Rotating Machinery Probe
The 330905-00-08-10-02-CN is a compact 3300 NSv proximity probe designed for vibration, displacement, and position monitoring in rotating machinery applications where standard-sized probes cannot be installed due to restricted mounting space. As part of the 3300 XL NSv Transducer System, it provides accurate proximity measurements for machinery protection and condition monitoring systems.
This model features an M10×1 threaded housing, an 80 mm case length, and a 1.0 meter standard cable with a miniature coaxial ClickLoc connector. Its compact construction allows installation in applications with counter bore, side-view, or rear-view limitations while maintaining reliable signal transmission and measurement stability.
The 330905-00-08-10-02-CN incorporates improved chemical resistance compared with older 3300 RAM designs, making it suitable for harsh industrial environments such as process compressor systems. Patented TipLoc and CableLoc technologies strengthen mechanical reliability by securing the probe tip and cable against vibration and installation stress.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 330905-00-08-10-02-CN NSV Probe |
| Manufacturer | Bently Nevada |
| Product Type | NSV Probe |
| Part Number | 330905-00-08-10-02-CN |
| Dimensions | 1.8x1.6x111cm |
| Weight | 0.06kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Unthreaded Length Option | 00=Minimum unthreaded length: 0 mm |
| Overall Case Length Option | 08=80 mm |
| Total Length Option | 10=1.0 meter (39 in) |
| Connector and Cable-Type Option | 02=Miniature coaxial ClickLoc connector, standard cable |
| Probe dc Resistance | 4.2 ± 0.5 ohms |
| Operating Temperature | -52°C to +177°C (-62°F to +351°F) |
| Storage Temperature | -52°C to +177°C (-62°F to +351°F) |
Q1: What machinery applications is 330905-00-08-10-02-CN suitable for?
A1: The 330905-00-08-10-02-CN is suitable for compressors, turbines, motors, pumps, and fluid-film bearing machinery requiring compact vibration monitoring solutions.
Q2: What thread type does 330905-00-08-10-02-CN use?
A2: The 330905-00-08-10-02-CN uses an M10×1 threaded mounting configuration.
Q3: What is the total cable length of 330905-00-08-10-02-CN?
A3: The 330905-00-08-10-02-CN includes a 1.0 meter (39 inch) standard cable.
Q4: What connector type is used in 330905-00-08-10-02-CN?
A4: The 330905-00-08-10-02-CN uses a miniature coaxial ClickLoc connector with positive locking action.
Q5: What is the operating temperature range of 330905-00-08-10-02-CN?
A5: The 330905-00-08-10-02-CN operates from −52°C to +177°C (−62°F to +351°F).
Q6: Is 330905-00-08-10-02-CN compatible with older systems?
A6: Yes, the 330905-00-08-10-02-CN is backward compatible with older 3300 RAM and certain 3000-/7000-series systems.
Q7: What technologies improve the durability of 330905-00-08-10-02-CN?
A7: The 330905-00-08-10-02-CN uses patented TipLoc and CableLoc technologies for improved probe tip and cable strength.
