Product Name: Analog Input Module - RTD
Brand Name: ABB
Model Number: AI830A 3BSE040662R1
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB AI830A 3BSE040662R1 Analog Input Module - RTD |
| Manufacturer | ABB |
| Product Type | Analog Input Module - RTD |
| Part Number | AI830A 3BSE040662R1 |
| Estimated shipping dimensions | 4.4x11x11.8cm |
| Weight | 0.24kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Signal specification | 3-wire RTD: Pt100, Cu10, NI100, Ni120 and resistive potentiometer |
| Number of channels | 8 |
| CMRR, 50Hz, 60Hz | >120 dB (at 10Ω load) |
| NMRR, 50Hz, 60Hz | >60 dB |
| Rated insulation voltage | 50 V |
| Dielectric test voltage | 500 V a.c |
| Power dissipation | 1.6 W |
| Current consumption +5 V Modulebus | 70 mA |
| Current consumption +24 V Modulebus | 50 mA |
| resolution | 14 Bit |
The ABB AI830A 3BSE040662R1 is a high-precision temperature measurement module designed for industrial automation systems. It is used to acquire and process RTD (Resistance Temperature Detector) signals, enabling accurate temperature monitoring in process control applications.
The module supports multiple 3-wire RTD types, including Pt100, Cu10, Ni100, and Ni120, as well as resistive potentiometer inputs. With 8 input channels and 14-bit resolution, it provides stable and accurate signal conversion for multi-point temperature measurement tasks.
Engineered for integration into ABB automation systems, the AI830A ensures reliable communication via the module bus and delivers robust signal processing performance even in electrically noisy industrial environments.
High Measurement Resolution
The ABB AI830A 3BSE040662R1 provides 14-bit resolution, ensuring accurate and stable temperature signal conversion.
Excellent Noise Immunity
With CMRR greater than 120 dB and NMRR above 60 dB, the module effectively suppresses electrical noise and signal interference.
Multi-Sensor Compatibility
It supports multiple 3-wire RTD types including Pt100, Cu10, Ni100, and Ni120, as well as potentiometer inputs for flexible application use.
Multi-Channel Measurement Capability
The 8-channel configuration enables simultaneous monitoring of multiple temperature points within a single module.
Low Power Consumption Design
With a power dissipation of only 1.6 W, it supports energy-efficient operation in continuous industrial environments.
Strong Industrial Integration
Designed for ABB module bus systems, it ensures seamless integration into distributed control and automation architectures.
The ABB AI830A 3BSE040662R1 delivers reliable and precise temperature measurement performance through its 14-bit resolution signal conversion system. It ensures accurate acquisition of RTD inputs across 8 channels, making it suitable for multi-point temperature monitoring in industrial environments.
The module provides strong signal stability even in electrically noisy conditions, supported by high common-mode rejection ratio (CMRR >120 dB) and strong noise rejection capability. This ensures consistent data quality for critical process control applications.
Designed for efficient industrial operation, the AI830A consumes low power while maintaining high measurement accuracy. Its integration into ABB module bus systems enables fast and reliable data transmission, supporting stable long-term operation in automation and process control systems.
1. What is the main function of the AI830A 3BSE040662R1?
The AI830A 3BSE040662R1 is used for acquiring and processing RTD temperature signals in industrial automation systems.
2. How many input channels does the AI830A 3BSE040662R1 support?
The AI830A 3BSE040662R1 provides 8 analog input channels for temperature measurement.
3. What types of sensors are compatible with the AI830A 3BSE040662R1?
The AI830A 3BSE040662R1 supports Pt100, Cu10, Ni100, Ni120 RTD sensors and resistive potentiometers.
4. What is the resolution of the AI830A 3BSE040662R1?
The AI830A 3BSE040662R1 provides 14-bit measurement resolution.
5. How does the AI830A 3BSE040662R1 handle electrical noise?
The AI830A 3BSE040662R1 uses high CMRR (>120 dB) and NMRR (>60 dB) to suppress electrical interference.
6. What is the power consumption of the AI830A 3BSE040662R1?
The AI830A 3BSE040662R1 has a low power dissipation of 1.6 W.
