ABB AI895 3BSC690086R1 Analog Input Module

ABB AI895 3BSC690086R1 Analog Input Module

Product Name: Analog Input Module

Brand Name: ABB

Model Number: AI895 3BSC690086R1

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb ai895 3bsc690086r1 analog input module-1

Overview
Contact Info
Parameter
Introduction
Features
Function
FAQ
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB AI895 3BSC690086R1 Analog Input Module
Manufacturer	ABB
Product Type	Analog Input Module
Part Number	AI895 3BSC690086R1
Estimated shipping dimensions	4.5x10.5x12cm
Weight	0.24 kg
Place of shipment	Xiamen, China
Country of origin	Sweden
Signal specification	4...20 mA
Number of channels	8
Signal type	Unipolar single ended
Resolution	12 bit
Isolation	Groupwise isolated from ground
Under/over range	1.5 / 22 mA
Error	Typ. 0.05%, Max. 0.1%
Temperature drift	Typ. 100 ppm/°C
Input filter (rise time 0-90%)	20 ms
Temperature, Operating	0 to +55 °C (+32 to +131 °F)
Temperature, Storage	-40 to +70 °C (-40 to +158 °F)

Introduction

The ABB AI895 3BSC690086R1 is an analog input module designed for ABB distributed control systems. It is used to acquire and process analog field signals, primarily 4–20 mA current loop signals, from industrial sensors and transmitters.

With 8 input channels and high-resolution 12-bit signal conversion, the AI895 ensures accurate and reliable measurement of process variables such as pressure, temperature, flow, and level in industrial automation applications.

The module is engineered for stable performance in demanding environments, offering electrical isolation, signal filtering, and high measurement accuracy for continuous process control.

Features

8-channel analog input module for ABB distributed control systems
Supports standard 4–20 mA industrial signal acquisition
12-bit resolution enabling accurate process measurement
Groupwise isolation from ground for improved electrical safety and noise immunity
High measurement accuracy with typ. 0.05% and max. 0.1% error
Built-in signal conditioning with 20 ms input filtering (0–90% response)
Supports under-range (1.5 mA) and over-range (22 mA) detection
Low temperature drift performance (typ. 100 ppm/°C)
Designed for stable operation in continuous process environments
Compact industrial form factor (4.5 × 10.5 × 12 cm)
Lightweight design (0.24 kg) for easy installation and replacement
Operating temperature range from 0°C to +55°C
Storage temperature range from -40°C to +70°C
Suitable for harsh industrial automation environments
Optimized for reliable long-term analog signal acquisition
Compatible with ABB DCS and process control architectures

Function

The primary function of the ABB AI895 3BSC690086R1 is to convert analog 4–20 mA field signals into digital data that can be processed by ABB control systems.

It collects real-time measurements from industrial sensors and ensures accurate signal conditioning through filtering, isolation, and high-resolution conversion. This allows the control system to monitor and regulate process variables with high precision.

The module is widely used in applications requiring stable and accurate analog signal acquisition for process automation and control.

Typical applications include:

Industrial process automation
Power generation plants
Oil and gas industries
Chemical and petrochemical processing
Water and wastewater treatment
Manufacturing systems
Distributed control systems (DCS)

FAQ

1. What type of isolation does the ABB AI895 3BSC690086R1 use?

The ABB AI895 3BSC690086R1 uses groupwise isolation from ground for safety and noise reduction.

2. What industries use the ABB AI895 3BSC690086R1?

The ABB AI895 3BSC690086R1 is used in power plants, oil and gas, chemical processing, water treatment, and manufacturing industries.

3. What signal type does the ABB AI895 3BSC690086R1 support?

The ABB AI895 3BSC690086R1 supports 4–20 mA analog current loop signals.

4. What is the resolution of the ABB AI895 3BSC690086R1?

The ABB AI895 3BSC690086R1 has a 12-bit resolution for analog signal conversion.

5. What is the accuracy of the ABB AI895 3BSC690086R1?

The ABB AI895 3BSC690086R1 has a typical error of 0.05% and a maximum error of 0.1%.

6. What is the input filtering time of the ABB AI895 3BSC690086R1?

The ABB AI895 3BSC690086R1 has an input filter rise time of 20 ms.
