Product Name:Analog Output
Brand Name:ABB
Model Number:AO895 3BSC690087R1
Country of Origin: ASEA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
AO895 3BSC690087R1 |
Country of Origin: |
ASEA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
ABB AO895 |
|
Order Number |
3BSC690087R1 |
|
Series |
S800 I/O |
|
Channel Type |
Analog Output (AO) |
|
Number of Channels |
8 Channels |
|
Output Signal |
0(4)...20 mA |
|
Load Resistance |
Max 750 Ω |
|
Communication |
HART Protocol |
|
Safety Type |
Intrinsic Safety (IS) |
|
Compatible Units |
TU890 / TU891 |
|
Power Requirement |
24 V DC |
|
Dimensions (H×W×D) |
4.5x10.5x11.8cm |
|
Weight |
0.22kg |
|
Mounting Type |
Module termination system |
|
System Compatibility |
ABB 800xA / S800 I/O |
The ABB AO895 3BSC690087R1 is an advanced analog output module designed for the ABB S800 I/O system, delivering reliable signal conversion and precise current output control for industrial automation processes. It supports 8 analog output channels with 0(4)...20 mA signals, ensuring accurate process regulation in critical applications.
The AO895 module integrates intrinsic safety (IS) functionality with built-in HART communication, enabling intelligent field device diagnostics and enhanced system connectivity. It is designed for use with TU890 or TU891 termination units, ensuring safe and flexible installation in distributed control environments.
As part of ABB’s S800 I/O portfolio, the 3BSC690087R1 provides stable performance, high reliability, and seamless integration with ABB 800xA systems, making it suitable for demanding industrial control applications.
Q1: What is ABB AO895 used for?
A1: It is used for analog signal output in ABB S800 I/O systems for industrial process control.
Q2: How many output channels does 3BSC690087R1 support?
A2: It provides 8 analog output channels.
Q3: Does AO895 support HART communication?
A3: Yes, it supports HART for advanced field device diagnostics.
Q4: What signal range does AO895 output support?
A4: It supports 0(4)...20 mA analog output signals.
Q5: Which termination units are compatible with AO895?
A5: It is compatible with TU890 and TU891 module termination units.
