Product Name: Bridge Controller
Brand Name: ABB
Model Number: BRC300 PHCBRC30000000
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB BRC300 PHCBRC30000000 Bridge Controller is an industrial-grade control and communication coordination unit designed for system bridging and advanced drive control applications. It is used to manage and coordinate communication between control systems and power drive equipment in complex automation architectures. Supporting a wide power range from 0.55 kW to 5600 kW and voltage levels from 230 V to 690 V, the BRC300 is suitable for demanding industrial environments. It operates with Direct Torque Control (DTC) technology, enabling precise motor control and high-performance system response.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB BRC300 PHCBRC30000000 Bridge Controller |
| Manufacturer | ABB |
| Product Type | Bridge Controller |
| Part Number | BRC300 PHCBRC30000000 |
| Weight | 0.3 kg |
| Estimated shipping dimensions | 3.5x32.2x17.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Functional Positioning | System bridging and control communication coordination unit |
| Rated Current | 2 A |
| Operating Voltage | 5 V DC |
| Power range | 0.55 kW to 5600 kW |
| Voltage level | 230 V to 690 V |
| Control mode | Direct torque control (DTC) |
| Protection level | IP20, IP21, IP42, IP54, IP55, IP65 |
Wide Power and Voltage Adaptability
The BRC300 supports a broad operating range from 0.55 kW to 5600 kW and 230 V to 690 V, making it suitable for both small and large industrial drive systems.
Advanced Direct Torque Control Technology
The use of DTC enables faster torque response and higher precision compared to conventional scalar or vector control systems.
Flexible Protection Options
With multiple protection ratings from IP20 to IP65, the ABB BRC300 can be adapted to different installation environments and industrial conditions.
High-Level System Integration
The controller is designed for seamless communication coordination between drives and control systems, improving overall automation efficiency.
Industrial Reliability and ABB Engineering Quality
Built to ABB standards, the BRC300 ensures stable operation, long service life, and dependable performance in heavy-duty industrial applications.
The ABB BRC300 PHCBRC30000000 is designed for industrial automation environments and operates with a 5 V DC control supply and a rated current of 2 A. It is suitable for installation in systems ranging from low to very high power applications, supporting voltage levels from 230 V to 690 V. The device can be used in various enclosure protection conditions, including IP20, IP21, IP42, IP54, IP55, and IP65, depending on the installation configuration. It should be installed in appropriate industrial control cabinets or drive system enclosures, with consideration for ventilation, temperature control, and electromagnetic compatibility requirements.
Q1: Why is ABB BRC300 PHCBRC30000000 used in industrial systems?
The BRC300 PHCBRC30000000 is used because it provides reliable system bridging, advanced DTC control, and scalable integration for complex industrial drive applications.
Q2: What control method does ABB BRC300 PHCBRC30000000 use?
The BRC300 PHCBRC30000000 uses Direct Torque Control (DTC) for high-precision motor control and fast torque response.
Q3: What is the power range supported by ABB BRC300 PHCBRC30000000?
The BRC300 PHCBRC30000000 supports power systems ranging from 0.55 kW to 5600 kW.
Q4: What voltage levels can ABB BRC300 PHCBRC30000000 handle?
The BRC300 PHCBRC30000000 supports voltage levels from 230 V to 690 V.
Q5: What is the operating voltage of ABB BRC300 PHCBRC30000000?
The BRC300 PHCBRC30000000 operates on a 5 V DC control supply.
Q6: What protection levels are available for ABB BRC300 PHCBRC30000000?
The BRC300 PHCBRC30000000 supports multiple protection levels, including IP20, IP21, IP42, IP54, IP55, and IP65 depending on configuration.
